Philips DCM105 - Electrical Partslist

10 - 1
ELECTRICAL PARTSLIST
MAIN BOARD ASSEMBL
Y
C24 996510029538 E.CAP 3300UF 25V (-/98/12)
C24 996510029551 E.CAP 4700UF 25V +-20% (-/05)
D4 996510027488 CHIP DIODE SOD323 BZX384-C3V9
D7 996500042437 CH-DIODE SS14 SMA/DO-214AC
F1
!
994000001222 FUSE RADIAL LT 2A 250V
IC2 996500039806 IC UE2314 (-/98/12)
IC2 996510014303 IC UE2314 (-/05)
IC201 996510006827 IC (SANYO) LA6541NHL-TE-L-E
IC202 996510029534 IC (SANYO) LC78603E-8628E
IC203 996510006828 IC (SANYO) LA9242M-MPB-E
IC8 996510018861 IC SI4702
Q11 996510021976 IC LM78L05A (-/98/12)
Q11 996500040320 IC LM78L06 (-/05)
Q17 994000004145 TRANSISTORS B772Y (160-320)
Q19 996510020216 TRANSISTORS D882F
Q2 994000004145 TRANSISTORS B772Y (160-320)
Q202 996510003996 TRANSISTORS KTA1273
Q22 994000004145 TRANSISTORS B772Y (160-320)
U2 996500039808 IC SM LM324D
U3 996510018962 IC UTC7805
X201 994000004551 CRYSTAL 16.9344MHZ +-20PPM
XT3 996500042441 X'TAL 32.768KHZ -20PPM
POWER/ECO BOARD ASSEMBL
Y
C66
996510029551
E CAP 4700UF 25V + 20%
C66
996510029551
E
.
CAP 4700UF 25V +
-
20%
D1 996510020774 SMD DIODE BAS316
D37 996510020774 SMD DIODE BAS316
F2
!
994000004599 FUSE RADIAL T3.15A 250V
IC1 996510000882 IC TFA9842BJ
J002 994000003661 SPK JACK PT-22V11
Q13 996510000337 SMD TRANSISTORS BC847B (-/98)
Q4 996510000337 SMD TRANSISTORS BC847B (-/98)
Q6 996510000337 SMD TRANSISTORS BC847B (-/98)
C301 ! 994000001225 SAFETY CAP 275V 0.22UF -20% (-/05/12)
F101 ! 994000001222 FUSE RADIAL LT 2A 250V (-/05/12)
Q303 996500040320 IC LM78L06 (-/05/12)
RL301 ! 996500039818 RELAY ME-7-006-HSL DC6V AC10A (-/05/12)
T102 ! 996510030965 TRANSFORMER EI28 230V TO8599A (-/05/12)
Note: Only these parts mentioned in the list are
normal service parts.
