QUICK START QUIDE 3
English
Quick Start Guide
Connecting to a Television
Connecting to a Television and Recorder
Example TV set, rear panel
Set Top Box rear panel
UHF Aerial
SCART input on TV
SCART cable
(supplied)
SCART output
to TV
RF in connector
Set Top Box
Power Supply Adaptor
(supplied)
12V DC
Example VCR set, rear panel
Example TV set, rear panel
UHF Aerial
SCART input on TV
SCART cable
(supplied)
12V DC
SCART to SCART
cable (not supplied)
RF cable
VCR RF In connector
VCR RF Out connector
SCART
to VCR
Set Top Box Power
Supply Adaptor
(supplied)
Set Top Box, rear panel
RF In
connector
RF Out
connector
SCART output
to TV
