9
2. Setting up the monitor
3. Remove the hinge cover from
monitor body by using your fingers.
4. Use a screwdriver to remove the
screws on the arm,and then detach
the arm/stand from the monitor.
Note
This monitor accepts a 100mm x 100mm
VESA-Compliant mounting interface.
VESA Mounting Screw M4. Always
contact manufacturer for wall-mount
installation.
100mm
100mm
Warning
This product is curve design, when
attach / detach the base, place the
protective material under the monitor
and do not press down the monitor to
avoid the damage.
Note
Please purchase the appropriate wall
mount; otherwise the distance between
the back-plug-in signal cable and the
wall would be too short.
-5°
0° 90°
* Display design may differ from those
illustrated.
Warning
• To avoid potential screen damage,
such as panel peeling, ensure that
the monitor does not tilt downward
by more than -5 degrees.
• Do not press the screen while
adjusting the angle of the monitor.
Grasp only the bezel.
