Explanation of Symbols
vi EarlyVue VS30 Instructions for Use
Rear Panel Symbols
The following symbols may appear on the rear panel of the EarlyVue VS30.
Rear Panel Label Symbols
The following symbols may appear on the rear panel label of the EarlyVue VS30.
Symbol Name Standard/Reference
USB port NA
Ethernet port NA
Nurse call connector NA
VGA output NA
Electrostatic-sensitive device IEC 60747-5134
Follow Instructions for Use ISO 7010
¥
M002
¥ ISO 7010 Graphical symbols - Safety colours and safety signs - Registered safety signs
Symbol Name Standard/Reference
Catalog number ISO 15223-1* 5.1.6
Date of manufacture ISO 15223-1* 5.1.3
Unique Device Identifier (datamatrix
barcode)
NA
† IEC 60417 Graphical symbols for use on equipment
* ISO 15223-1 Medical devices - Symbols to be used with medical device labels, labelling and information to be supplied - Part
1: General requirements
REF
UDI
