Philips EarlyVue VS30 User Manual

EarlyVue VS30 Instructions for Use v
Explanation of Symbols
Measurement Connector Symbols
The following symbols may appear next to the measurement connectors on and under
the left panel of the EarlyVue VS30, or on the rear of the optional predictive temperature
module.
Symbol Name Standard/Reference
General warning sign IEC 60601-1
Defibrillator Proof Type CF applied part IEC 60417
†
5336
SpO
2
SpO
2
connector NA
CO
2
CO
2
connector NA
NBP connector NA
CO
2
output connector NA
CO
2
input connector NA
Temperature connector ISO 7000** 0034
Predictive temperature connector NA
Microstream™ NA
Masimo SET
®
and Masimo rainbow SET™ NA
† IEC 60417 Graphical symbols for use on equipment
** ISO 7000 Graphical symbols for use on equipment - Registered symbols
