MECHANICAL & ACCESSORIES PARTS LIST - MAIN UNIT SCREW LISTS - MAIN UNIT
185 D3 x 12
211 D3 x 12
213 D3 x 12
214 D3 x 12
277 D3 x 12
278 D3 x 12
280 D3 x 12
282 D3 x 12
283 D3 x 16
284 M3 x 15
285 D3 x 16
286 D3 x 12
288 D3 x 12
289 D3 x 12
290 D3 x 12
293 D3 x 12
294 D2 x 8
297 D3 x 12
298 D3 x 12
299 D3 x 12
0101 313911810640 Cabinet Front
0105 313911810440 Window CDC Control
0106 313911789360 Button Set CDC Select
0107 313911810990 Cover Tray CDC 2
0108 482245413408 Badge Philips
0124 313911812780 Window Display /21M
0124 313911811030 Window Display /22/34
0125 313911810690 Button DBB
0127 313911467670 Lightguide DSC C10
0131 313911810590 Button Set Prog
0132 313911789410 Button Power On/Off
0133 313911467730 Button Set Source Select
0135 313911810760 Button Set Controls
0136 313911810400 Lightcap Source Select
0139 313911469930 Button Clock/Timer /21M
0139 313911469930 Button RDS/News/Clk /22/34
0143 313911789440 Cover Ring DSC
0144 313911789450 Cover Ring Volume
0145 313911789460 Button DSC
0146 313911810930 Knob Volume Rotary
0153 313911812790 Cover Control 2 /21M
0153 313911810710 Cover Control 2 /22/34
0158 313911810660 Cover Cassette Left 2
0159 313911810670 Cover Cassette Right 2
0160 313911468520 Lens Cassette Left 2
0161 313911468530 Lens Cassette Right 2
0197 482244310488 Door Cassette Right
0198 482244310487 Door Cassette Left
0199 482240210621 Push-Catch
0200 482252910322 Damper Assembly
0203 482249211344 Spring Compression
0204 482240211246 Bracket Right
0205 482240211245 Bracket Left
0208 482249211345 Spring Tension
0209 482249242787 Spring Cassette
0251 313911469840 Cabinet Rear NMI /21M/34
0251 313911469820 Cabinet Rear MIH /22
0252 482246240683 Foot Rubber SQ
0255 482246693148 Spacer 5mm
0260 482249211734 Spring IC
0350 313911877280 Loudspeaker Box FB-C28
0351 482230350063 FM Aerial 75R
0356 313922883610 Remote Control RC282425/01
0384 482230350082 AM Frame Aerial
0385 482232110249
!
Mains Cord
0387 313911520060 Instruction For Use /21M
0387 313911619330 Instruction For Use /22
0387 313911619340 Instruction For Use /34
1451 482232012604 Flex Cable 9pin 22cm
1455 482232012654 Flex Cable 7pin 22cm
1456 313911034180 Flex Cable 16pin 22cm
1557 482232012663 Flex Cable 7pin 34cm
5001 313911832230
!
Mains Transformer /21M
5001 313911832130
!
Mains Transformer /22/34
LEFT/RIGHT LOUDSPEAKER BOX BREAKDOWN
482224810008 Piezo with Wire Assembly
996500002117 Speaker 4" 6R 12W
Note: Only the parts mentioned in this list are normal
service spare parts.
