11-2 11-2
MECHANICAL & ACCESSORIES PARTS LIST - MAIN UNIT SCREW LISTS - MAIN UNIT
191 D3 x 12
192 D2 x 6
193 D3 x 12
194 D3 x 12
226 M3 x 6
227 M3 x 10
228 M3 x 6
229 D3 x 12
230 M3 x 12
231 M3 x 6
232 M3 x 6
276 M3 x 6
277 M3 x 10
278 D3 x 16
279 D3 x 12
280 D3 x 12
283 D3 x 12
287 D3 x 12
288 D3 x 12
292 M3 x 12
293 M3 x 12
294 M3 x 6
295 D3 x 12
296 D3 x 12
299 D2 x 8
300 D3 x 12
301 D3 x 12
302 D3 x 10
303 D3 x 10
304 D3 x 12
305 D3 x 12
306 D3 x 12
307 D3 x 12
308 D3 x 12
309 D2 x 8
310 D3 x 10
311 D2 x 8
312 D3 x 12
313 D3 x 12
314 D3 x 12
0101 3139 118 19641 Cabinet Front
0102 3139 257 50911 Panel Front 5DTC
0107 3139 114 77741 Lightguide 5DTC Play 1
0108 3139 114 77751 Lightguide 5DTC Play 2
0109 3139 114 77761 Lightguide 5DTC Play 3
0110 3139 114 77771 Lightguide 5DTC Play 4
0111 3139 114 77781 Lightguide 5DTC Play 5
0114 3139 118 19701 Cover Tray 5DTC 1
0115 3139 118 19711 Cover Tray 5DTC 2
0116 3139 118 19721 Cover Tray 5DTC 3
0117 3139 118 19731 Cover Tray 5DTC 4
0118 3139 118 19741 Cover Tray 5DTC 5
0120 3139 257 50931 Panel Front Display
0121 3139 118 19671 Panel Front Control USB /21
0121 3139 257 50921 Panel Front Control USB /22
0122 3139 118 19751 Button ECO/Standby Power
0123 3139 114 77901 Lightguide Power ECO
0124 3139 114 77911 Lightguide IR
0125 3139 118 19761 Cover Ring FTD
0126 3139 118 19791 Window Display FTD
0128 3139 118 19771 Cover Ring VU Meter 1 (Left)
0129 3139 114 78261 Bracket VU Meter 1 (Left)
0131 3139 114 77721 Button Set 5DTC Play
0132 3139 114 77921 Button DIM
0133 3139 114 77941 Button PROG
0134 3139 114 77931 Button CLOCK
0135 3139 118 19781 Cover Ring VU Meter 2 (Right)
0136 3139 114 78271 Bracket VU Meter 2 (Right)
0138 3139 114 79051 Button Set Source Select
0148 3139 118 19831 But Set DBB/DSC/VAC
0150 3139 118 19901 Cover Orn MAX
0151 3139 114 78071 Button MAX
0160 3139 118 19841 Button Set Func Control
0161 3139 118 19861 Cover Ring Func Control Foil
0162 3139 257 50951 Cap Func Control
0163 3139 118 19891 Cover Ring Volume Foil
0164 3139 114 78031 Knob Volume Rotary
0165 3139 118 19881 Cap Knob Volume
0166 4822 492 51374 Ring
0170 3139 114 78161 Lightguide Game Sound
0171 3139 118 19921 Button MIX-IT/Game Mode
0173 3139 114 78201 Cover Game Port
0174 3139 114 78191 Bracket Game Port
0176 3139 118 19931 Knob Game Sound Control
0177 4822 492 51374 Ring
0182 3139 114 78381 Holder Led USB
0183 3139 114 78301 Bracket PCB Front Display
0185 3139 114 72750 Bracket CDC Left
0186 3139 114 72760 Bracket CDC Right
0246 3139 113 27140 Foot Rubber 4mm
0253 3139 114 79081 Panel Left
0254 3139 114 79101 Panel Right
0255 3139 114 78341 Cover Top
0256 3139 114 78231 Panel Rear
0266 3139 114 78241 Bracket Fan
0271 3139 114 71010 Stopper Heatsink
0347 3139 119 00721 L/R Loudspeaker Box
0351 2422 076 00546 Cable FM Aerial
0352 4822 303 50082 Antenna AM Loop
0353 3139 228 61791 Remote Control
0356 2422 070 98151
!
Mains Cord
0357 3139 128 73010
!
Adaptor Plug /21
0358 4822 263 21206 Cable Cinch/1M7/Cinch
0364 2422 076 00523 Cable USB-A/USB-B 1M5 4P
0369 3139 119 00891 CD-ROM USB PC LINK
Installer SW
0370 3139 115 22791 Instruction For Use /21
0370 3139 115 22391 Instruction For Use /22
0371 3139 115 22581 Instruction For Use /22
(E. Europe Language)
1104 3103 308 66991 PBAS USB PC LINK
1121 2822 031 01494 Fan 12VDC 0,8W 3100RPM
5001 3139 118 32580
!
Mains Transformer /21
5001 3139 118 32570
!
Mains Transformer /22
5900 3139 110 53451 Meter VU
5901 3139 110 53451 Meter VU
8202 3139 110 35350 FFC Foil 11P/220/11P AD
8203 3139 110 35010 FFC Foil 07P/340/07P AD
8404 3139 111 02511 FFC Foil 08P/300/08P AD Fold
8405 3139 110 35280 FFC Foil 10P/120/10P AD
8407 3139 110 34920 FFC Foil 08P/280/08P BD
8408 3139 111 02491 FFC Foil 19P/280/19P AD
8410 3139 111 02501 FFC Foil 05P/180/05P AD Fold
8412 3139 110 35031 FFC Foil 08P/140/08P AD
8413 3139 110 35400 FFC Foil 09P/340/09P AD
8415 3139 110 34600 FFC Foil 07P/280/07P AD
8417 3139 110 36150 FFC Foil 15P/280/15P AD
8501 3139 110 33940 FFC Foil 04P/180/04P BD
8601 3139 111 02481 FFC Foil 08P/180/08P AD
L/R LOUDSPEAKER BOX BREAKDOWN
9965 000 18384 Kendo Mask
9965 000 03233 Grommet (Dia. 11 mm)
9965 000 18390 Woofer 6,5" 6R 135W
9965 000 18386 Woofer Ring
9965 000 18391 Tweeter 2" 6R
9965 000 18388 Tweeter Ring
9965 000 18389 Rubber Foot (20 x 11 x 3 mm)
Note : Only the parts mentioned in this list are normal
service spare parts.
