ELECTRICAL PARTSLIST
MAIN BOARD ASSEMBL
Y
AV401 996510018097 RCA JACK RCA-S-06
FS1102
!
994000002784 GLASS FUSE 6.3A 250V TSD
FS1103
!
996510018095 GLASS FUSE 1.6A 250V TSD TIME
IC301
I.C. TDA8947J4 HEADPHONE AMP
IC302 994000005026 IC SC7314
IC303
I.C. TOSHIBA TC4052
IC402
ZENER I.C. CW7809CS
IC403
I.C. LM2576-TO220V
IC404 996510008103 I.C. KA7805 POSITIVE VOLTAGE
JK301 994000001722 SPEAKER TERMINAL WP-408
JK302
RCA JACK RED/WHITE
Q301 994000005028 TRANSISTOR 8550B/C
Q302 994000005041 TRANSISTOR 8050C/D
Q303 994000005028 TRANSISTOR 8550B/C
Q304 994000005028 TRANSISTOR 8550B/C
Q307 994000005041 TRANSISTOR 8050C/D
Q309 994000005041 TRANSISTOR 8050C/D
Q315 996510018096 SMT TRANSISTOR 8550B/C(SOT23)
Q401 996510008094 TRANSISTOR B772Y
Q403 994000005041 TRANSISTOR 8050C/D
Q406
TRANSISTOR 2SC-945P NEC
DVD BOARD ASSEMBL
Y
FB1 SMT IND 100MHz 1000mA
FB2 996510018070 SMT IND 100MHz 1000mA
FB3 996510018070 SMT IND 100MHz 1000mA
Q10 996510008798 SMT TRANSISTOR 2N3906
Q11 996510008798 SMT TRANSISTOR 2N3906
Q12
SMT TRANSISTOR 2N3904
Q13 996510018068 SMT TRANSISTOR 2N3904
Q14 996510008798 SMT TRANSISTOR 2N3906
Q21 996510018068 SMT TRANSISTOR 2N3904
Q9 996510008798 SMT TRANSISTOR 2N3906
U2 996510008924 SMT I.C SA5888
U6 I.C. SANYO LB1641
U7
SMT IC.HUAJING CF4558CB AZ1309
X1 996510008800 CRYSTAL 27 MHz
MIC BOARD ASSEMBL
Y
IC601 996510008923 SMT I.C BA4558F
JK601 996510018071
STEREO EARPHONE JACK MSJ2000
JK602 996510018071
STEREO EARPHONE JACK MSJ2000
VR601 996510018072
SHAFT VOLUME 50K FB20B7.0-B503
Note: Only these parts mentioned in the list ar
e
normal service parts.
