ELECTRICAL PARTSLIST
RECTIFIER BOARD ASSEMBLY
C1118
CERAMIC CAP 0.01 UF/400V +80%
FS1101
GLASS FUSE 1A 250V 50T TIME
L1101
FERRITE BEAD12.5x7.5x0.65 mm
SW1101
AC ADAPTOR 110-220V VSC-22-1
USB BOARD ASSEMBL
Y
JK303 996510018078 HEADPHONE JACK CKX-3.5-42 YEL
JK901 996510018077 USB CONNECTOR 4 PIN 1.25mm R
DISPLAY BOARD ASSEMBL
Y
IC701 996510018085 SMT I.C. HT1622BD
IC702 996510018086 WINBOND(A)
IC703 996510018087
SMT IC.HT1381
IC704 996510018088 SMT IC AT24C02(256X8) 1.8V
IR701 996510018082
DIODE SM338AL 3.3V
JOG701 996510018080 POTARY ENCODER EC12E224204F20
LCD701 996510018081 LCD DISPLAY
LED701 996510018079 LED
SW701 994000002786 TACT SWITCH 2P
SW703 994000002786 TACT SWITCH 2P
SW707 994000002786 TACT SWITCH 2P
SW708 994000002786 TACT SWITCH 2P
SW709 994000002786 TACT SWITCH 2P
SW710 994000002786 TACT SWITCH 2P
SW711 994000002786 TACT SWITCH 2P
SW712 994000002786 TACT SWITCH 2P
SW713 994000002786 TACT SWITCH 2P
SW714 994000002786 TACT SWITCH 2P
SW716 994000002786 TACT SWITCH 2P
WS706 994000002786 TACT SWITCH 2P
X701 996510018083 CRYSTAL 10 MHZ HC-49US
X702 996510018084 CRYSTAL 32.768 KHz +-20PPM 2P
LED BOARD ASSEMBL
Y
AW715 994000002786 TACT SWITCH 2P
LED702 996510018089 LED ROUND TYPE 3mm RED
SW704 994000002786 TACT SWITCH 2P
Note: Only these parts mentioned in the list ar
e
normal service parts
.
!
!
