Philips GC7530 - Disassembly Advice - Stand; Parts List - Stand

GC7530
5-8
TRAY RUBBER CAP 30
TRAY ASSY 33
DOOR ASSY
Remove TRAY RUBBER CAP 30 (3x)
Remove Screw F1, F2, F3
Disassemble TRAY ASSY 33
Remove Screw G
Disassemble DOOR ASSY
FRONT PANEL PRINTED 37
POWER BOARD 43
CONTROL BOARD
Remove TRAY RUBBER CAP 30 (3x)
Remove Screw F1, F2, F3
Disassemble TRAY ASSY 33
Remove Screw H1, H2
Disassemble FRONT PANEL 37
Remove Screw J1, J2
Disassemble PCB BRACKET
Disassemble CONTROL BOARD
Disassemble POWER BOARD 43
WATER TANK ASSY 34
HOSE CORD CAP 36
BOILER ASSY 38
BRAIDED RUBBER HOSE -
BOILER
PUMP ASSY 45
INLET TUBE - PUMP
DE-AIR TUBE
RINSE RUBBER COUPLING 50
RINSE BUSH
RINSE CAP ASSY 52
Remove TRAY RUBBER CAP 30 (3x)
Remove Screw F1, F2, F3
Disassemble TRAY ASSY 33
Remove Screw H1, H2
Disassemble FRONT PANEL 37
Disassemble HOSE CORD CAP 36
Disassemble RINSE CAP ASSY 52
Disassemble RINSE BUSH
Disassemble RINSE RUBBER COUPLING 50
Remove Screws K1, K2, K3, K4
Disconnect INLET TUBE - PUMP
Disconnect DE-AIR TUBE
Disassemble WATER TANK ASSY 34
Disassemble BRAIDED RUBBER HOSE - BOILER
Disassemble PUMP ASSY 45
Remove Torx screws L1, L2, L3
Disassemble TOP SPACER
Disassemble BOILER ASSY 38
DISASSEMBLY ADVICE - STAND
PARTS LIST - STAND
Note: For Pos 45, please replace both components together when either one is faulty.
The 2 components come as a service kit.
Pos Service code Description Remark
30
33
34
36
37
4239 015 59631
4239 021 68791
4239 021 68961
4239 026 48491
4239 021 68931
Tray rubber cap
Tray assy
Water tank assy
Hose cord knob
Front panel
Purple
White
Purple
Purple
Printed
38
40
42
4239 021 39541
4239 017 09892
4239 010 10261
Boiler assy
Electrovalve
Inox clamp
High End
Pos Service code Description Remark
43
45
50
52
4239 021 68611
4239 022 66221
4239 015 56761
4239 021 68881
Power board
Control board-
Pump assy kit
Rinse rubber coupling
Rinse cap assy Purple
55
56
65
2422 070 98366
4239 021 68721
4239 026 42081
Cord set
Stand bottom assy
De-air valve
EU
White
High End
