Philips GC8520 - Iron Disassembly Procedures; Basic Iron Component Removal; Hose, Cord, and Thermostat Dial Disassembly; Housing and Steam Deviator Removal

GC8520
2-7
BACKPLATE 21
INLAY
SOS KNOB 10
LAMP ASSY
MICROSWITCH ASSY 4
HOSE CORD CABLE
ASSY 13
THERMOSTAT DIAL 20
HOUSING PRINTED 6
SUB-HOUSING
STEAM DEVIATOR ASSY 12
COVER SOS MOLDED 3
SOS SEAL 11
SOLEPLATE
MOUNTED ASSY 1
Remove Screw A
Disassemble BACKPLATE 21
Disassemble INLAY
Disassemble SOS KNOB 10
Disengage Ribs of light ring
Disassemble LAMP ASSY
Remove Screw B
Disassemble Switch holder
Disassemble MICROSWITCH ASSY 4
Remove Screws C1, C2, C3
Disassemble HOSE CORD CABLE ASSY 13
Disassemble THERMOSTAT DIAL 20
Remove Screws D1, D2, D3, D4
Disassemble HOUSING PRINTED 6
Remove Screw E
Disassemble SUB-HOUSING
Disassemble STEAM DEVIATOR ASSY 12
Remove Screws F1, F2, F3
Disassemble COVER SOS MOLDED 3
DISASSEMBLY ADVICE - IRON
