Philips GC8520 - Iron Exploded View and Fasteners; Iron Assembly Exploded View; Screw Identification for Iron

GC8520
4-7
EXPLODED VIEW - IRON
10
20
18
6
3
1
11
Light ring
Switch holder
12
5
4
21
2
13
19
F2
F1
F3
E
D3
D4
D1
C1
C2
C3
A
D2
B
Screw Dimension
A,C,E Ø 3.5 mm x 13 mm
B,D Ø 2.6 mm x 9.6 mm
F1 M4.0 mm x 10 mm
F2,F3 M4.0 mm x 16 mm
