Philips GC8620 - Stand Parts List; Stand Component Identification

GC8620
7-12
POWER BUTTON PRINTED 37
BUTTON FRAME PRINTED 38
POWER BOARD PCB-PUMP
SERVICE KIT 39
POWER CORD EU 40
STAND BOTTOM MOLDED 41
Remove Screw N1, N2, N3, N4, N5
Disassemble WATER TANK ASSY 23
Remove Screw S1, S2, S3
Disassemble POWER BUTTON PRINTED 37
Disassemble BUTTON FRAME PRINTED 38
Remove Screw T
Release INOX CLAMP 26 (2x)
Disassemble BRAIDED RUBBER HOSE BOILER 27
Disconnect Wires
Disassemble POWER BOARD PCB-PUMP
SERVICE KIT 39
Remove Screw U1, U2
Disassemble Cord clamp
Disassemble POWER CORD EU 40
Disassemble STAND BOTTOM MOLDED 41
DISASSEMBLY ADVICE - STAND
PARTS LIST - STAND
Pos Service code Description
17
19
20
21
23
4239 026 50134
4239 015 59731
4239 026 51861
4239 021 70852
4239 021 71523
Filling door molded
Tray rubber cap
Tray cap molded
Tray printed
Water tank assy
24
25
26
27
28
4239 021 70862
4239 015 59791
4239 010 10261
4239 015 59771
4239 017 12802
Rinse cap assy
Safety cap
Inox clamp
Braided rubber hose Boiler
Electrovalve
29
30
31
32
33
4239 026 51241
4239 021 72612
4239 026 49732
4239 015 59751
4239 021 69891
Spacer top
Rinse housing cap printed
Rinse housing molded
O-ring
Boiler assy
34
35
36
37
38
4239 026 42581
4239 026 32181
4239 021 69951
4239 021 70772
4239 021 70762
Boiler support bracket
Spacer bottom
Boiler thermistor assy
Power button printed
Button frame printed
39
40
41
4239 022 67101
2422 070 98399
2422 070 98412
4239 026 50432
Power board PCB-Pump service kit
Power Cord EU
Power Cord UK
Stand bottom molded
