Philips GC9550 Service Manual

GC9550
9-12
WIRING DIAGRAM
LEGEND:
Female Push-on 4.8 x 0.8 mm L-shape Connector
Female Push-on 5.2 x 0.8 mm L-shape Connector
Male Tab Terminal 4.8 x 0.8 mm
Female Push-on L-shape Connector 6.35 x 0.8 mm
Piggy Back Push-on Connector 4.8 x 0.8 mm
Male Tab Terminal 6.35 x 0.8 mm
Female Push-on Connector 6.35 x 0.8 mm
Sleeve - Fiber Glass
Insulated Tab - Silicon Rubber
Ring Terminal M4.3
Splice 6.0 mm
Directly soldered on PCB
7-pin Board-in Connector 2 mm (horizontal)
7-pin Connector 2 mm (vertical)
POWER BOARD
HALL
SENSOR
BOARD
HOSCORD
FLEX ASSY
IRON
UI
BOARD
9013 (Live)
9016 (Pump-Control)
9015 (Evalve-Control)
THERMAL
FUSE (L)
THERMISTOR TRIGGER NEUTRAL
9014 (Live)
WA1 : PCB-Pump (L)
WA2 : PCB-Pump (ctrl)
WA7 : PCB-EV (ctrl)
WA4 : PCB-EV (L)
WA5 : PCB-Fuse (L)
WA19 : HE-Fuse (L)
WA6 : PCB-Fuse (N)
9003 (Boiler-L)
3
2
1
3
2
1
2
1
9009 (Boiler-N)
9001 (Live) 9002 (Neutral)
9018 (Iron LED)
9007
9004 (Iron Live)
9006 (To UI)
PUMP
EVALVE-EARTH
7x
2x
3x
H
VsF
sFsF
F
sF mF
mF sF
sF
sF
sPB sM
sM
F
M
sF
F
F
MM#1
#1
#2
#1
#1
#2
#2
THERMAL
FUSE (N)
sFsF
#2#1
#2
F
F
F
H
V
M
M
M
WA20 : HE-Fuse (N)
WA3 : EARTH WIRE_BOILER
THERM-BOILER
sPB
9012
(3.96 mm)
9017
