HD7892/60 /61
9-15
Parts list
Pos Service code Description Remark
1720 Lid spring
1730 Hose
1740 Lever Deep black
1750 Lever frame
1760 Rod (2x)
1770 Slider left
1780 Slider right
1790 Slider spring
17100 Lid frame
17110 4222 240 05991 Ejector pin (2x)
17120 4222 247 08121 BC seal
17130 4222 247 72611 Distribution disk
17140 Brewchamber bottom Black
18 4222 247 72573 Inner frame
19 4222 259 65982 Main PCBA SENSEO Switch 220 - 240 V
20 4222 247 08101 L-bend
21 4222 240 02041 Hose clamp
22 4222 259 61291 Pressure hose assy
23 4222 247 75502 Base plate Fusion black
24 4222 247 69442 Suspension bracket
25 4222 244 50693 Tie wrap boiler
26 4222 259 37244 Pump ULKA HF 230 V
˜
50 Hz
27 4222 247 43690 Boiler pin cover
28 Hose valve assy
29 4222 247 69552 TCO cover
30 Boiler assy TCO Metal - 230 V
3010 4222 259 53272 Boiler Metal - 230 V
3020 4222 247 05134 O-ring (NTC)
3030 4222 240 00892 Bracket
3040 4222 259 60501 NTC
3050 4222 248 56582 Screw
3060 4222 248 56001 TCO
31 4222 247 08252 Hose socket
32 4213 247 05256 Foot
33 4222 247 06301 Pump damper
100 4222 244 50680 Tie wrap
