Philips HD7892/60 - Parts List

HD7892/60 /61
8-15
Parts list
Pos Service code Description Remark
1 4222 259 65942 Padholder assy Switch 1-cup Deep black
110 Padholder 1-cup
120 Co ee spout 1-cup Deep black
2 4222 259 65952 Padholder assy Switch 2-cup Deep black
210 Padholder 2-cup
220 Co ee spout 2-cup Deep black
3 4222 247 75762 Top collector Deep black
4 4222 247 75782 Driptray cover Deep black
5 4222 247 75772 Driptray Deep black
6 4222 259 67511 Filter holder assy incl. Lid
610 Filter holder lid
620 Filter holder
7 4222 259 63771 Thermal jug assy incl. Lid Black
8 9965 100 70806 Thermal jug lid Black
9 4222 247 75141 Co ee spoon
10 4222 259 65932 Water container assy incl. Lid Deep black
1010 Water container lid Deep black
1020 Valve seal
1030 Valve spring
1040 Valve rod
1050 Float spring
1060 Float assy
1070 Water container Transparent
11 4222 259 60072 One way valve
12 4222 247 75522 Housing Deep black
13 4222 247 59473 Sensor housing
14 4222 259 65902 Top cover assy Deep black
1410 Top cover Deep black
1420 Buttons rubber
1430 Buttons plastic
1440 UI house top
1450 UI PCBA
1460 UI house bottom
15 4222 259 65892 Back plate assy Deep black
1510 WC Sealing
1520 Filter
1530 WC Socket
16 4222 247 72692 Lid cover Deep black
17 4222 259 66712 Brew chamber assy Deep black
1710 Lid hinge cover
