1 INTRODUCTION TO THE HEARTSTART FR2+
DEVICE DESCRIPTION
The HeartStart FR2+ Defibrillator (“FR2+”) is a compact, lightweight, portable,
and battery powered automated external defibrillator designed for use by a
trained responder to treat ventricular fibrillation (VF), the most common cause
of sudden cardiac arrest (SCA).
The FR2+ has a Status Indicator that is always active, so you can tell at a glance if
it has passed its last selftest. The front panel of the FR2+ has an On/Off button
at the top and a Shock button at the bottom. A display screen in the center of
the panel provides text prompts and incident information. Voice prompts are
provided through a speaker located at the base of the FR2+. See the diagram on
the inside front cover for details.
The FR2+ is available in two models, the M3860A and the M3861A. They share a
set of basic features, detailed in Chapter 6. The principle differences between
the two models are identified below:
NOTE:The FR2+ comes with a factory default setup that can be modified.
(See Chapter 6, “Configuration, Setup, and Advanced Mode Features,” for a
description of setup defaults and options.)
INDICATIONS FOR USE
The HeartStart FR2+ is intended to be used with disposable defibrillator pads
applied to victims of sudden cardiac arrest exhibiting the following symptoms:
• Unresponsiveness
• Absence of normal breathing
If in doubt, apply the pads.
Model M3860A Model M3861A
Configurable ECG display on screen Text prompt display on screen, no
ECG display
Configurable manual charge in
advanced mode (See Chapter 6)
No manual charge in advanced mode
(See Chapter 6)
