PHILIPS MEDICAL SYSTEMS
B
B-3
energy Using adult defibrillator pads: 150 J nominal (±15%) into a 50 ohm load. Using
infant/child reduced-energy defibrillator pads: 50 J nominal (±15%) into a 50
ohm load. Sample pediatric energy doses:
age energy dose
newborn 14 J/kg
1 year 5 J/kg
2 - 3 years 4 J/kg
4 - 5 years 3 J/kg
6 - 8 years 2 J/kg
Doses indicated are based on CDC growth charts for the 50th percentile
weights for boys.*
* National Center for Health Statistics in collaboration with the National Center for Chronic
Disease Prevention and Health Promotion. CDC growth charts: weight-for-age percentiles, revised
and corrected November 28, 2000. Atlanta, GA: Centers for Disease Control and Prevention
© 2000.
charge control Controlled by Patient Analysis System for automated operation. Can be
programmed for manual initiation using advanced mode of the M3860A.
charge time
from “shock advised”
< 10 seconds, including confirming analysis.
NOTE: Charge time increases near end of battery service life.
manual mode charge time < 5 seconds.
Quick Shock End of “Stop CPR” prompt to armed time: < 10 seconds.
“charge complete”
indicator
Shock button flashes, audio tone sounds.
disarm (AED mode) Once charged, the HeartStart FR2+ will disarm if:
• patient’s heart rhythm changes to non-shockable rhythm,
• a shock is not delivered within 30 seconds after the FR2+ is armed,
• the Pause button (if enabled) is pressed,
• the On/Off button is pressed to turn off the FR2+, or
• the defibrillator pads are removed from the patient or the pads connector
is disconnected from the FR2+.
category nominal specifications
