PHILIPS MEDICAL SYSTEMS
B-6
DISPLAY
CONTROLS AND INDICATORS
category nominal specifications
monitored ECG lead ECG information is received from adult defibrillator pads in anterior-anterior
(Lead II) position or from FR2 infant/child reduced-energy defibrillator pads
in anterior-posterior position. (Displayed on M3860A only.)
ECG information can also be displayed in the M3860A using the FR2+ ECG
assessment module.
NOTE: The ECG display provided by the FR2+ Defibrillator is not intended to
provide diagnostic or ST segment interpretation.
display range
(M3860A only)
Differential: ±2 mV full scale, nominal.
screen type High-resolution liquid crystal display (LCD) with backlight.
screen dimensions 2.8" wide x 2.3" high (70 mm x 58 mm).
sweep speed
(M3860A only)
23 mm/s nominal.
ECG display 3 second-segments displayed (M3860A only).
frequency response
(bandwidth)
Nondiagnostic rhythm monitor 1 Hz to 20 Hz (-3 dB), nominal.
sensitivity 1.16 cm/mV, nominal.
heart rate displayed
(normal sinus rhythm)
30 to 300 bpm, updated each analysis period. Displayed (M3860A only)
during monitoring and advanced modes.
category nominal specifications
LCD screen High-resolution, backlighted LCD screen, displays text messages and
(model M3860A only) ECG.
controls On/Off button
Shock button
Option buttons
LED indicators Connector socket LED, flashes to indicate socket location. LED is covered
when defibrillator pad connector is properly inserted. Shock button LED
flashes when defibrillator is armed.
