3-3
PHILIPS MEDICAL SYSTEMS
3
STEP 2: PLACE THE PADS
Pull the tab at the top of the pads cartridge to peel off the film seal. Inside are two
adhesive pads on a plastic liner. Remove the pads from the cartridge.
Peel one pad off the liner. Place the pad on the patient’s bare skin, exactly as shown
in the picture on the pad. Press the pad down firmly. Then repeat this with the other
pad. Be sure the pads have been removed from the liner before placing them.
NOTE: It may be necessary to dry the patient’s skin where the pads will be
placed, or to clip or shave excessive chest hair, in order to provide good
contact between the pads and the skin.
Pad placement for adults and children
more than 55 pounds or 8 years old.
Pad placement for infants
or children less than 55
pounds or 8 years old.
