Philips HR 8901 - Page 3

HR 8... .901 .903 .905 .907 .909 Description
Pos
1
2
4822 466 12261
4822 466 12258
4822 466 12256
4822 442 01914
4822 442 01911
----X
-XX--
X--X-
----X
-XX--
cord-winder pedal
cord-winder pedal
cord-winder pedal
accessory cover
accessory cover
3
4
4822 442 01906
4822 492 11044
4822 442 01915
4822 442 01912
4822 442 01907
X--X-
XXXXX
----X
-XX--
X--X-
accessory cover
acc. cover spring
lead lid
lead lid
lead lid
5
6
7
8
9
4822 417 11264
4822 532 12374
4822 528 10943
4822 532 70286
4822 442 01916
XXXXX
XXXXX
XXXXX
XXXXX
----X
acc. cover lock
diaphragm valve
swivel connector
sealing rubber
dust cover
10
11
4822 442 01908
4822 442 01913
4822 492 11045
4822 460 11148
4822 460 11146
X--X-
-XX--
XXXXX
----X
X--X-
dust cover
dust cover
dust-cover spring
dust-cover snaplock
dust-cover snaplock
12
13
4822 460 11147
4822 402 10108
4322 009 07200
4322 009 07210
4322 009 07220
-XX--
XXXXX
X----
-XX--
-- -X-
dust-cover snaplock
cord-winder lever
version panel
version panel
version panel
14
15
4822 466 12262
4822 466 12263
4822 466 12257
4822 466 12259
4822 214 11309
----X
----X
X--X-
-XX--
----X
version panel
switch pedal
switch pedal
switch pedal
PCB
16
4822 214 11308
4822 214 11407
4822 214 11913
4822 214 11912
4822 015 70057
-- -X-
-- -X-
----X
-- -X-
XXXXX
PCB 230V/50Hz
PCB 220V/60Hz
PCB rem. control 100-127V
PCB eco/auco 100-127V
paper dustbag hyg.
17
18
19
20
4822 480 10072
4822 530 10246
4822 256 10155
4822 320 11181
4822 441 11625
(X) (X) (X) (X) (X)
X X X (X) (X)
XXXXX
----(X)
XXXXX
cotton dustbag
suction hose (460)
dustbag holder
connecting cable
dust chamber
21
22
23
24
25
4822 492 71489
4822 466 10776
4822 532 52554
4822 528 10836
4822 290 81474
XXXXX
XXXXX
XXXXX
XXXXX
XXXXX
reel half spring unit
connection piece
brake tyre
reel half contact unit
contact-ring plate
26
27
28
29
4822 321 10816
4822 321 10822
4822 321 11348
4822 321 10818
4822 321 10783
XXXXX
XXXXX
XXXXX
XXXXX
XXXXX
cordset Australia / Argentina
cordset Japan (2 x 1.25 mm
2
)
cordset (2 x 0.75 mm
2
)
cordset UK
cordset L = 8.3 m 4.8 mm pins
30
31
32
33
34
4822 321 10806
4822 321 10815
4822 441 12375
4822 528 10925
4822 271 30856
XXXXX
XXXXX
XXXXX
XXXXX
XXXX-
cordset
cordset
lower housing
caster assy
micro-switch
35
36
37
38
39
4822 492 11009
4822 404 40703
4822 402 10111
4822 276 13205
4822 441 12379
XXXXX
XXXXX
XXXX(X)
XXXXX
----X
button spring
switch lever
parking hook
main switch
button panel
40
40A
41
4822 441 12376
4822 441 12378
4822 441 12377
4822 460 11097
4822 480 10228
X--X-
-XX--
XXXXX
XXXXX
-----
button panel
button panel
upper housing with buffer
buffer
safety trio filter (opt.)
PCS 101 241
