English
15
3 Turn the shaping disc holder counterclockwise to
remove it from the mixing chamber outlet.
4 Put your finger in the mixing chamber and push the squeezing tube
outwards to slide it out of the mixing chamber outlet. Detach the shaping
disc, and then pull the squeezing bar out of the squeezing tube.
5 Take the mixing paddle out of the mixing
chamber.
6 Clean all detachable parts and accessories, and then wipe them dry.
1
2
3
