Philips HTB3510 Service Manual

Safety instruction
1. General safety
Safety regulations require that during a repair:
. Connect the unit to the mains via an isolation transformer.
. Replace safety components indicated by the symbol
,
only by components identical to the original ones. Any
other component substitution (other than original type)
may increase risk of fire or electrical shock hazard.
Safety regulations require that after a repair, you must
return the unit in its original condition. Pay, in particular,
attention to the following points:
. Route the wires/cables correctly, and fix them with the
mounted cable clamps.
. Check the insulation of the mains lead for external
damage.
. Check the electrical DC resistance between the mains
plug and the secondary side:
1) Unplug the mains cord, and connect a wire between
the two pins of the mains plug.
2) Set the mains switch the “on” position (keep the
mains cord unplug).
3) Measure the resistance value between the mains
plug and the front panel, controls, and chassis
bottom.
4) Repair or correct unit when the resistance
measurement is less than 1M
¡
.
5) Verify this, before you return the unit to the
customer/user (ref. UL-standard no. 1492).
6) Switch the unit “off”, and remove the wire between
the two pins of the mains plug.
2.Laser safety
This unit employs a laser. Only qualified service personnel
may remove the cover, or attempt to service this device
(due to possible eye injury).
Laser device unit
Type : Semiconductor laser GaAlAs
Wavelength : 650nm (DVD)
: 780nm (VCD/CD)
Output power : 7mW (DVD)
: 10mW (DVD /CD)
Beam divergence: 60 degree
Note: Use of controls or adjustments or performance of
procedure other than those specified herein, may result in
hazardous radiation exposure. Avoid direct exposure to
beam.
Safet
y
instruction, Warnin
g
& Notes
1-7

Philips HTB3510 Specifications

General

Number of satellite speakers	4
Satellite speakers RMS power	532 W
Satellite speaker frequency range	150 - 20000 Hz
Satellite speaker woofer diameter (imperial)	3 \
Center speaker type	1-way
Subwoofer type	Passive subwoofer
Subwoofer frequency range	20 - 150 Hz
Subwoofer driver diameter (imperial)	1 \
FM radio	Yes
Supported radio bands	FM
AC input voltage	220-240 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	105 W
MP3 bit rates	32 - 320 Kbit/s
Audio decoders	DTS, DTS-HD Master Audio, Dolby Digital, Dolby Digital Plus, Dolby TrueHD
RMS rated power	1000 W
Audio output channels	5.1 channels
Audio formats supported	AAC, FLAC, MKA, MP3, OGG, WAV, WMA
Total Harmonic Distortion (THD)	30 %
Package depth	327 mm
Package width	394 mm
Package height	596 mm
Package weight	11220 g
Built-in HDD	No
Channels quantity	40 channels
Image formats supported	GIF, JPG, PNG
Disc types supported	BD, BD-R, BD-RE, CD, CD-R, CD-RW, DVD, DVD+R, DVD+RW, DVD-R, DVD-RW
Playback disc formats	SVCD, VCD
Number of optical discs	1 discs
Optical disc player type	Blu-Ray player
Video formats supported	AVCHD, AVI, DIVX, DIVX HD, H.264, ISO, MP4, MPEG, MPEG1, MPEG2, MPEG4, MPG, WMV, WMV9
Product color	Black
Playback modes	Rotation, Zoom
Wi-Fi	-
Consumer Electronics Control (CEC)	EasyLink
Cables included	AC
HDMI in	0
USB version	2.0
HDMI version	1.4
Number of HDMI outputs	1

Weight and Dimensions

Main unit weight	266 g
Subwoofer weight	3660 g
Center speaker weight	650 g
Main unit dimensions (WxDxH)	435 x 286.5 x 56.3 mm
Subwoofer dimensions (WxDxH)	178 x 343 x 300 mm
Front speaker dimensions (WxDxH)	90 x 82 x 185 mm
Center speaker dimensions (WxDxH)	223 x 80 x 100 mm
