5 Wall mount
your SoundBar
Before you mount your SoundBar on the wall,
read all safety precautions.
Wall mount
Note
• You must detach the surround speakers from the main
unit before wall mounting or un-mounting.
• P&F USA, INC. bears no responsibility for improper
wall mounting that results in accident, injury or damage.
If you have any query, contact Philips Consumer Care
in your country.
• Secure the wall mount to a wall that can support the
combined weight of the product and the wall mount.
• Before wall mount, you need not remove the four
rubber feet at the bottom of the soundbar, otherwise
the rubber feet cannot be xed back.
Screw length/diameter
Depend on the type of wall mounting this wall
mount bracket, make sure that you use screws
of a suitable length and diameter.
For information about how to wall your
SoundBar, see the wall mount guide.
> 25mm
3 - 3.5mm
6 Product
specifications
Note
• Specications and design are subject to change without
notice.
Amplier
• FTC total output power: 66W*
• Front Left + Right: 16W (1% THD,
8ohm, 150 Hz - 20 kHz)
• Surround Left + Right: 20W (1% THD,
8ohm, 150 Hz - 20 kHz)
• Subwoofer: 30W (1% THD, 4ohm, 30
Hz - 140 Hz)
• Total output power:
• 210W RMS (+/- 0.5 dB, 30% THD)
• 168W RMS (+/- 0.5 dB, 10% THD)
• Frequency response: 20 Hz-20 kHz /
±3 dB
• Signal-to-noise ratio: > 65 dB (CCIR) /
(A-weighted)
• Input sensitivity:
• AUX: 400 mV
• AUDIO-IN: 200 mV
* FTC output power is measured in bypass
mode. To enter bypass mode, in AUX mode,
press and hold AUTO VOLUME OFF for 5
seconds. To exit bypass mode, turn off the unit
and switch it on again.
Audio
• S/PDIF Digital audio input:
• Coaxial: IEC 60958-3
• Optical: TOSLINK
Bluetooth
• Bluetooth proles: A2DP
