Philips HTS3544/37 - Mechanical Part List

9 - 2 9 - 2
MECHANICAL PART LIST
Loc. Part No. Description
1 996510001254 DISPLAY LENS
2 996510016361 FRONT PANEL HIPS
3 996510001256 STANDY BUTTON
4 996510001257 OPEN/CLOSE BUTTON
5 996510001662 STANDY LED LENS
6 996510003834 OPEN /CLOSE BUTTON HOLDER
7 996510001259 FUNCTION BUTTON RING
8 996510001269 VOLUME KNOB RING
9 996510001261 VOLUME KNOB RING
10 996510001262 FUNCTION BUTTON
11 996510016360 DVD DOOR ABS
12 996510007576 SOURCE BUTTON
13 996510003836 SOURCE BUTTON HOLDER
15 996510003837 VFD FILTER
18 996510016363 BOTTOM CAB SECC
23 996510016362 BACK PANEL SECC
24 996500042571 FAN DC 12V 0.1A 4000RPM
25 996510001615 FAN COVER
26 996510007321 TOP CAB
27 994000005305 RUBBER FOOT
28 996510003875 PVC SHEET
34 996510010819 DVD LOADER
35 996510016357 POWER PCB ASS’Y
36 996510016358 MAIN PCB ASS’Y
37 996510016359 IPOD PCB ASS’Y
38 996510001252 PWR CORD
39 996510016364 TUNER PACK
A1 996510016356 CTRL+USB+PHONEJACK+STANDBY+BKT
DOCK 996510010855 SIMPLE IPOD DOCK
FM 996510008251 FM ANTENNA 1000MM
VIDEO 996500013058 RCA CABLE 2P 1.2M
V3 996510013767 FFC CABLE 24P
V1 996510007429 FFCCBLE 10P
RC 996510001263 REMOTE CONTROL
SPEAKER
RFC 996510001599 RUBBER FOOT -CENTER SPK
RFF 996510001600 RUBBER FOOT-FRONT SPK
RFR 996510001601 RUBBER FOOT - REAR SPK
RFS 996500028375 RUBBER FOOT
SPKC 996510017698 SPEAKER BOX -CENTER
SPKFL 996510017699 SPEAKER BOX -FRONT LEFT
SPKFR 996510017700 SPEAKER BOX - FRONT RIGHT
SPKRL 996510017701 SPEAKER BOX- REAR LEFT
SPKRR 996510017702 SPEAKER BOX- REAR RIGHT
SUBW 996510017703 SUBWOOFER
