Philips HTS5530 - Connecting External Audio Sources; Microphone Connection

8
Option 2: Connect audio through coaxial
cable
Note
• The digital coaxial cable or connector might be
labeled COAXIAL/DIGITAL OUT or SPDIF
OUT .
(Cable not supplied)
Connect a microphone
(Microphone not supplied)
TV
Option 3: Connect to the TV through
composite video (CVBS)
Note
• The composite video cable or connector might
be labeled AV IN , VIDEO IN , COMPOSITE or
BASEBAND .
Connect audio from TV or
other devices
Use your home theater to play audio from the
TV or other devices such as a cable box.
Tip
• Press AUDIO SOURCE repeatedly to select
the audio output of your connection.
Option 1: Connect audio through analog
audio cables
TV
TV
EN
