IntelliVue Smart-hopping 1.4 GHz Access Point Installation Guide 2-1
2
Installing the IntelliVue Smart-hopping 1.4 GHz Core
Access Point
This chapter provides procedures to physically install the Philips IntelliVue
Smart-hopping 1.4 GHz Core Access Point and includes:
• Access Point Placement Guidelines
• ITS4843D Installation Procedure
• ITS4843B and ITS4843C Installation Procedure
• Mounting the IntelliVue Smart-hopping Core AP to a Wall (Fixed Mount)
• Mounting the IntelliVue Smart-hopping Core AP to a Wall (CA
Earthquake Rated)
• Mounting the IntelliVue Smart-hopping Core AP Above a Ceiling Tile
• Mounting the IntelliVue Smart-hopping Core AP Below a Ceiling Tile
(Fixed Mount)
• Mounting the IntelliVue Smart-hopping Core AP Below a Ceiling Tile
(Quick Release)
• Mounting the IntelliVue Smart-hopping Remote Antenna to a Wall
(Fixed Mount)
• Mounting the IntelliVue Smart-hopping Remote Antenna to a Wall (CA
Earthquake Rated)
• Mounting the IntelliVue Smart-hopping Remote Antenna Above a
Ceiling Tile (Mounting Rails)
• Mounting the IntelliVue Smart-hopping Remote Antenna Above a
Ceiling Tile (Tether Mount)
• Mounting the IntelliVue Smart-hopping Remote Antenna Below a
Ceiling Tile (Fixed Mount)
• Mounting the IntelliVue Smart-hopping RA Below a Ceiling Tile (Quick
Release)
• AP Configuration Information
• Access Point Startup Sequence
