2-22
Chapter 2: Installing the IntelliVue Smart-hopping 1.4 GHz Core Access Point
10. Mount the Core AP to the wall plate by inserting the head of each shoulder
screw into the four mounting holes provided in the wall plate and then sliding
Figure 2-15: Mounting the Core AP Below a Ceiling Tile (Quick Release
Bend Down
Tighten Collar
Insert M3.5 Security Screw
through this View Port and
Tighten Using a Torx T10
Screwdriver.
