Mounting the IntelliVue Smart-hopping Remote Antenna Above a Ceiling Tile (Mounting Rails)
IntelliVue Smart-hopping 1.4 GHz Access Point Installation Guide 2-29
Figure 2-18: Possible Above the Ceiling Remote Antenna Mounting Position
Use These Holes Marked as Noted
RM2 RM2
AM2 Unmarked
Grommets
Units: millimeters
inches
