Philips LC4.3E User Manual

Spare Parts List
EN 121LC4.3E AA 10.
10. Spare Parts List
Set Levels per CTN
26PF3320/10
1099h 9322 221 01682 LC260WX2-SL01 (LPL)
1099
h 9322 227 29682 QD26HL02
1099
h 9322 234 13682 LC260WX2-SLB2
1099
h 9322 235 05682 QD26HL02-REV02
1112 3139 188 89041 IR & LED Assy [J]
1114 3139 188 89031 Control Board [E]
1116 3139 188 89021 Side I/O Assy [G]
1174 3139 188 89051 Audio Amp. Assy [C]
1188
h 3122 137 23191 Power Supply Unit 26" [A]
8002 3104 311 08061 Cable 2p3/120/Inlet
8190 2422 076 00702 Cable DVI-I Cinch 3p
8520 3139 131 06081 Cable Inverter
8520 3139 131 06731 Cable 14p/280/14p
8684 3139 131 04421 Cable 3p/340/3p
8870 3104 311 09151 Cable 6p/400/6p
8903 3104 311 09141 Cable 4p/560
8J02 3139 131 05901 Cable 12p/280/12p
8J03 3104 311 10051 Cable 3p/100/3p Wh
8J04 3104 311 09251 Cable 9p/140/9p
8K01 3104 311 10041 Cable 12p/280/12p Wh
8K01 3139 131 05901 Cable 12p/280/12p
8P06 3139 131 06001 Cable 30p/140/30p
b
5213 2422 264 00536 Loudsp. 5W fullrange
e Software (see Philips Service Website)
0606
0611
0626
26PF3320/10
1099 9322 221 27682 LCD QD26WL01
1099
h 9322 222 27682 LCD LC260W01
1114 3139 267 13391 Control Board [E]
1116 3139 267 14091 Side I/O Panel [G]
1174 3139 188 89051 Audio Amp. Assy [C]
1188
h 3122 137 23191 Power Supply Unit 26" [A]
8002 3104 311 08071 Cable 2P3/140
8190 2422 076 00702 Cable DVI-I Cinch 3p
8520 3139 131 05541 Cable 14p/140/14p
8540 3104 311 09461 Cable 6p/820/6p Wh
8540 3139 131 05051 Cable 06p/820/06P
8871 3139 131 06121 Cable 20p/100/20p
8903 3104 311 10551 Cable P/280 820/2x2
8903 3139 131 05771 Cable 04p/280
8J02 3104 157 02041 Cable 12p/340/12p Bk
8J03 3139 110 27651 Cable 3p/100/3p
8P06 3139 131 05941 Cable 30p/140/20p
b
5213 2422 264 00518 Loudsp. 8Ω 5W FR
e Software (see Philips Service Website)
0606
0611
26PF4310/10
1099 9322 221 01682 LC260WX2-SL01 (LPL)
1099
h 9322 226 15682 LQ255T3LZ33
1099 9322 234 13682 LC260WX2-SLB2
1112 3139 188 89041 IR & LED Assy [J]
1114 3139 188 89031 Control Board [E]
1114 3139 188 89032 Keyboard Assy [E]
1116
h 3139 188 89021 Side I/O Assy [G]
1116
h 3139 188 89022 Side I/O Assy [G]
1150 3139 188 89961 Small Signal Board [B]
1174 3139 188 89051 Audio Amp. Assy [C]
1188
h 3122 137 23191 Power Supply Unit 26" [A]
8002 3104 311 08061 Cable 2p3/120/Inlet
8002 3104 311 08071 Cable 2P3/140
8190 2422 076 00659 Cable vga\1k5\Cinch
RdGnBu
8520 3139 131 06081 Cable Inverter
8520 3139 131 06511 Cable 14p/280/14p
8684 3139 131 04421 Cable 3p/340/3p
8870 3104 311 09151 Cable 6p/400/6p
8903 3104 311 09141 Cable 4p/560
8903 3139 131 05311 Cable 04p/560
8J02 3139 131 05901 Cable 12p/280/12p
8J03 3104 311 10051 Cable 3p/100/3p Wh
8J03 3139 110 27651 Cable 3p/100/3p
8J04 3104 311 09251 Cable 9p/140/9p
8K01 3104 311 10041 Cable 12p/280/12p Wh
8K01 3139 131 05901 Cable 12p/280/12p
8P06 3139 131 06001 Cable 30p/140/30p
b
5213 2422 264 00536 Loudsp. 5W fullrange
e Software (see Philips Service Website)
0606
0611
0626
32PF3320/10
1099h 9322 227 30682 QD32HL02
1112
h 3139 188 89041 IR & LED Assy [J]
1114
h 3139 188 89031 Control Board [E]
1116
h 3139 188 89021 Side I/O Assy [G]
1174 3139 188 89051 Audio Amp. Assy [C]
1188 3122 137 23171 Power Supply Unit 32" [A]
8002
h 3104 311 08061 Cable 2p3/120/Inlet
8190 2422 076 00702 Cable DVI-I Cinch 3p
8520
h 3139 131 06511 Cable 14p/280/14p
8870 3104 311 09151 Cable 6p/400/6p
8903 3139 131 05321 Cable 4p/560
8J02 3139 131 05901 Cable 12p/280/12p
8J03 3139 110 27651 Cable 3p/100/3p
8J04 3104 311 09251 Cable 9p/140/9p
8K01 3104 311 10041 Cable 12p/280/12p Wh
8K01 3139 131 05901 Cable 12p/280/12p
8P06
h 3139 131 06971 Cable 30p/280/30p
b
5213 2422 264 00537 Loudsp. 4W 15W
e Software (see Philips Service Website)
0606
0611
0626
32PF5320/10
1099h 9322 217 44682 LC320W01-A6K1 (LPL)
1099
h 9322 226 16682 LQ315T3LZ33
1099
h 9322 229 23682 LC320W01-SL01
1099
h 9322 230 03682 LC320W01-SL06
1112 3139 188 89041 IR & LED Assy [J]
1114 3139 188 89031 Control Board [E]
1114 3139 188 89032 Keyboard Assy [E]
1116 3139 188 89021 Side I/O Assy [G]
1116 3139 188 89022 Side I/O Assy [G]
1174 3139 188 89051 Audio Amp. Assy [C]
1188
h 3122 137 23171 Power Supply Unit 32" [A]
8002 3104 311 08061 Cable 2p3/120/Inlet
8190 2422 076 00702 Cable DVI-I Cinch 3p
8520 3139 131 05641 Cable 12p/820 280/12p
8520 3139 131 06731 Cable 14p/280/14p
8520 3139 131 07611 Cable Inverter
8684 3139 131 04421 Cable 3p/340/3p
8870 3104 311 09151 Cable 6p/400/6p
8903 3139 131 05321 Cable 4p/560
8J02 3139 131 05901 Cable 12p/280/12p
8J03 3104 311 10051 Cable 3p/100/3p Wh
8J03 3139 110 27651 Cable 3p/100/3p
8J04 3104 311 09251 Cable 9p/140/9p
8K01 3104 311 10041 Cable 12p/280/12p Wh
8K01 3139 131 05901 Cable 12p/280/12p
8P06 3139 131 05471 Cable 30p/280/30p
b
5213 2422 264 00537 Loudsp. 4W 15W
e Software (see Philips Service Website)
0606
0611
0626
32PF5420/10
1099h 9322 226 16682 LQ315T3LZ33
1112 3139 188 89041 IR & LED Assy [J]
1114 3139 188 89031 Control Board [E]
1116 3139 188 89021 Side I/O Assy [G]
1116 3139 188 89022 Side I/O Assy [G]
1174 3139 188 89051 Audio Amp. Assy [C]
1188 3122 137 23171 Power Supply Unit 32" [A]
8002 3104 311 08061 Cable 2p3/120/Inlet
8520
h 3139 131 06731 Cable 14p/280/14p
8870 3104 311 09151 Cable 6p/400/6p
8903 3139 131 05321 Cable 4p/560
8J02
h 3139 131 05901 Cable 12p/280/12p
8J03 3104 311 10051 Cable 3p/100/3p Wh
8J03
h 3139 110 27651 Cable 3p/100/3p
8J04
h 3104 311 09251 Cable 9p/140/9p
8K01
h 3139 131 05901 Cable 12p/280/12p
8P06
h 3139 131 05471 Cable 30p/280/30p
b
5213 2422 264 00537 Loudsp. 4W 15W
e Software (see Philips Service Website)
0606
0611
0626
32PF7320/10
1091 2422 033 00016 Sckt DVI/29p VGA/15p f
1092 2422 076 00659 Cable vga\1k5\Cinch
RdGnBu
1099
h 9322 217 44682 LC320W01-A6K1 (LPL)
1099
h 9322 229 23682 LC320W01-SL01
1099
h 9322 230 03682 LC320W01-SL06
1112
h 3139 188 89041 IR & LED Assy [J]
1114 3139 188 89031 Control Board [E]
1116
h 3139 188 89021 Side I/O Assy [G]
1116
h 3139 188 89022 Side I/O Assy [G]
1150 3139 188 89011 Small Signal Board [B]
1174 3139 188 89051 Audio Amp. Assy [C]
1188
h 3122 137 23171 Power Supply Unit 32" [A]
8002 3104 311 08061 Cable 2p3/120/Inlet
8190 2422 076 00659 Cable vga\1k5\Cinch
RdGnBu
8520 3139 131 05641 Cable 12p/820 280/12p
8520 3139 131 06511 Cable 14p/280/14p
8520 3139 131 07611 Cable Inverter
8684 3139 131 04421 Cable 3p/340/3p
8870 3104 311 09151 Cable 6p/400/6p
8J02 3139 131 05901 Cable 12p/280/12p
8J03 3104 311 10051 Cable 3p/100/3p Wh
8J03 3139 110 27651 Cable 3p/100/3p
8J04 3104 311 09251 Cable 9p/140/9p
8K01 3104 311 10041 Cable 12p/280/12p Wh
8K01 3139 131 05901 Cable 12p/280/12p
8P06 3139 131 05471 Cable 30p/280/30p
b
5213 2422 264 00537 Loudsp. 4W 15W
e Software (see Philips Service Website)
0606
0611
0626
0635
Small Signal Board [B]
Various
1101 2422 025 18749 Connector 3p m
