Service Modes, Error Codes, and Fault Finding
EN 20 LC4.3E AA5.
Table 5-3 NVM Default values (option bit settings through NVM Editor in SAM Mode)
Byte Nr. Bit Feature/Mode Description
32PF7320/10
32PF5320/10
26PF5320/10
26PF4310/10
Byte 0
174(dec)
0 QSS (LSB) Mode of quasi split sound amplifier 1 1 1 1
1 FMI Connection of output of QSS amplifier 1 1 1 1
2 HCO EHT tracking mode 0 0 0 0
3 HP2 Synchronization of OSD/Text display 1 1 1 1
4 FSL Forced slicing level for vertical sync 1 1 1 1
5 TFR DC transfer ratio of luminance signal 1 1 1 1
6 OSVE Black current measuring in overscan 0 0 0 0
7 MVK (MSB) (For Future Usage, as defined by software) 0 0 0 0
Total Dec Values 59 59 59 59
Total Hex Values 3B 3B 3B 3B
Byte 1
175(dec)
0 PSE PSE 0 0 0 0
1OPC OPC 0 0 0 0
2PRIS PRIS 0 0 0 0
3 CONTINUOUS FACTORY Continuous factory mode 0 0 0 0
4 WHITE PATTERN ON Last color pattern status in factory mode 0 0 0 0
5 SDM MODE Service default mode on/off 0 0 0 0
6 SAM MODE Service Align mode on/off 0 0 0 0
7 SVMA Scavm On / Off 0 0 0 0
Total Dec Values 0 0 0 0
Total Hex Values 00 00 00 00
Byte 2
176(dec)
0 MUTE STATUS Mute status 0 0 0 0
1 TUNER AUTO MODE Auto mode 1 1 1 1
2 CABLE MODE Cable/Antenna mode 0 0 0 0
3 LAST POWER MODE Last power status of the set 1 1 1 1
4 CHILD LOCK MODE Child lock enabled 0 0 0 0
5 SURF MODE Surf mode on/off 0 0 0 0
6 FACTORY MODE Factory mode on 0 0 0 0
7 PSNS For PAL color enhancement in ES4 1 1 1 1
Total Dec Values 138 138 138 138
Total Hex Values 8A 8A 8A 8A
Byte 3
177(dec)
0 RADIO/TV MODE Radio mode or TV mode 0 0 0 0
1 WAKE-UP MODE WAKE-UP MODE 0 0 0 0
2 HOTEL MODE TV in Hotel mode 0 0 0 0
3 HOTEL KBD LOCK Keyboard locked 0 0 0 0
4HBL HBL 0 0 0 0
5 BLS Blue stretch mode 1 1 1 1
6SL SL 0 0 0 0
7 CFA0 Comb filter On/Off 0 0 0 0
Total Dec Values 32 32 32 32
Total Hex Values 20 20 20 20
Byte 4
178(dec)
0 Signal Strength Signal Strength Switch in MK2 0 0 0 0
1LPG LPG 0 0 0 0
2 DVD TRAY LOCK Lock/Unlock DVD tray 0 0 0 0
3 SCRSAVER MODE Screen saver mode 1 1 1 1
4 BKS Black Stretch Mode 1 1 1 1
5 BSD Black Stretch Depth 1 1 1 0
6 CRA0 Coring on SVM 1 1 1 1
7 PIP QSS PIP QSS 0 0 0 0
Total Dec Values 120 120 120 88
Total Hex Values 78 78 78 58
To Next Page
