LFH 0388/LFH 0488/LFH 0588
37
POS. DESCRIPTION SERVICE CODE LFH LFH LFH
0388 0488 0588
1 SPRING FOR CASS. FLAP 5322 492 71595 1 1 1
2 SLEEVE 5322 325 60392 1 1 1
3 CASSETTE FLAP 5103 107 69920 1 – –
3 CASSETTE FLAP 5103 107 71010 – 1 –
3 CASSETTE FLAP 5103 107 69600 – – 1
4 VA, SENS. BUTTON (Black) 5322 411 61818 1 2 –
4 VA, SENS. BUTTON (Blue) 5103 104 31480 – – 2
5 UPPER HOUSING 5103 109 26560 1 – –
5 UPPER HOUSING 5103 109 26590 – 1 –
5 UPPER HOUSING 5103 109 26600 – – 1
6 SPRING FOR RECORD RING 5322 492 71483 1 1 1
7 ERASE HEAD 5322 249 40315 1 1 1
8 LOUD SPEAKER 4 OHM (for Service) 5322 240 30599 1 1 1
9 CONTACT PLATE (BATT.) 5103 101 44490 1 1 –
9 CONTACT PLATE (BATT.) 5103 101 44480 – – 1
11 BATTERY LID 5103 107 69690 1 1 –
11 BATTERY LID 5103 107 69800 – – 1
12 SPINDLE 5103 101 23040 1 1 1
13 RIGHT HAND TURNTABLE 5322 528 10901 1 1 1
14 FUNCTION RING 5322 528 20776 1 1 1
15 RECORD BUTTON 5103 104 30970 1 1 –
15 RECORD BUTTON 5103 104 30900 – – 1
16 SPRING FOR SCAN. LEVER 5322 492 71482 1 1 1
17 SCANNING LEVER 5322 405 30116 1 1 1
18 BRAKE SPRING 5322 492 71481 1 1 1
19 ROLLER 5322 528 81523 1 1 1
20 SPRING FOR ROLLER 5322 492 52387 1 1 1
21 FAST FORWARD GEAR 5322 522 33451 1 1 1
22 SERVICE ROLLER LEVER 5322 405 30117 1 1 1
23 MOUNTING PLATE ASSY. 5103 109 26580 1 1 1
24 CONTACT SPRING (BATT.) 5103 101 04580 2 2 –
24 CONTACT SPRING (BATT.) 5322 492 71594 – – 2
25 VA-SENS-SWITCH LEVER 5103 104 31060 1 1 1
26 BATTERY COMPARTMENT 5103 104 31030 1 1 –
26 BATTERY COMPARTMENT 5103 104 31020 – – 1
27 FUNCTION SWITCH SK 1 5322 276 13482 1 1 1
28 SOCKET SO 1 5322 268 90445 1 1 1
29 CHARGING CONTACT 5103 101 04560 1 1 1
31 VA, SENS. SWITCH 5322 278 90628 1 2 2
32 SCREW 1 x 3 (Print) 5322 502 30674 3 3 2
33 LOWER HOUSING 5103 107 69670 1 – –
33 LOWER HOUSING 5103 107 71020 – 1 –
33 LOWER HOUSING 5103 107 69790 – – 1
34 SCREW 1,5 x 11 (Housing) 5322 502 30742 2 2 2
35 SCREW 1,5 x 20 (Housing) 5322 502 30743 2 2 2
36 SCREW 1,5 x 11 (Housing) 5322 502 30742 2 2 2
37 DAMPER FOR FLAP 5103 104 31460 2 2 2
38 REWIND WHEEL 5322 528 70842 1 1 1
39 MICROPHONE ASSY. 5322 242 30293 1 1 1
41 DISPLAY HOUSING 5103 107 71230 – – 1
Mechanical partslist
