Philips MC-200 - Mechanical Partslist; Parts and Accessories Listing

13 - 213 - 2
8
6
(2x)
6
4 (3x)
5
3 (3x)
6
8
(4x)
9 (2x)
8 (2x)
8 (2x)
8 (2x)
9(2x)
6 (2x)
6
6 (2x)
9 (2x)
437
438
439
441
446
SCREW LIST
1. T2 x 10
2. T2.5 x 10
3. T3 x 6
4. T3 x 8
5. T3 x10
6. T3 x12
7. P/W C2.5 x 10
8. P/W T3 x 6
9. P/W T3 x 10
503
504
506
MECHANICAL PARTSLIST
401 3140 117 61880 CASSETTE DOOR ASSY
402 3139 114 73920 DOOR CASSETTE ETF SD
403 4822 492 42787 SPRING CASSETTE
404 3140 114 40100 FRONT CABINET COVER
406 3140 117 61850 FRONT WINDOW ASSY
407 3140 117 59350 VOLUME KNOB ASSY
408 3140 117 61820 FRONT CABINET ASSY (/21 /30 /33)
408 3140 117 61830 FRONT CABINET ASSY/ RDS (/22)
409 4822 492 11344 SPRING COMPRESSION
411 4822 529 10322 DAMPER ASSY
412 4822 492 11345 SPRING TENSION
413 4822 402 11246 BRACKET CASSETTE-RIGHT
414 4822 402 10621 PUSH-CATCH
416 3140 114 40010 FRONT KNOBS SOURCE
417 3140 114 40020 FRONT KNOBS PROGRAM
418 3140 117 61870 CHROME KNOBS ASSY
419 3140 114 40110 FRONT KNOBS PRESET
421 3140 114 29180 LCD HOLDER
422 3139 118 78740 TAPE DECK CRL 4438
423 4822 529 10387 DAMPER - RUBBER (40 DEG)
424 4822 529 10386 DAMPER - RUBBER (30 DEG)
426 3103 309 05290 CD DA11N DRIVE ASSY
427 4822 529 10322 CD DRIVE COVER
428 3140 114 42590 CD-TRAY
429 4822 529 10322 DAMPER ASSY
431 4822 535 60096 DISC
432 4822 532 13153 RING (CD LID)
433 4822 532 12798 PRESSURE RING ASSY
434 4822 492 11741 SPRING CD
436 3140 117 61840 CD DOOR ASSY
437 4822 462 40692 RUBBER STAND
438 3140 114 29310 TUNER BRACKET
439 3140 114 40140 REAR CABINET
441 3140 113 21880 MAINS CORD RELIEF
446 4822 466 93148 PCB SPACER
Note: Only these parts mentioned in the list are normal
service parts.
ACCESSORIES
3140 118 51000 LOUDSPEAKER BOX ASSY
3140 118 51010 REMOTE CONTROL
4822 303 50063 FM AERIAL
4822 303 50082 MW LOOP AERIAL
3140 115 28690 I.F.U. /22
3140 115 28680 I.F.U. /21, /21M, /30
