6-5
ELECTRICAL PARTS LIST - FRONT DISPLAY BOARD
RESISTORS
4122 4822 051 30008 0R Jumper 0603
4123 4822 051 30008 0R Jumper 0603
4124 4822 051 30008 0R Jumper 0603
4125 4822 051 30008 0R Jumper 0603
4126 4822 051 30008 0R Jumper 0603
4127 4822 051 30008 0R Jumper 0603
4128 4822 051 30008 0R Jumper 0603
4129 4822 051 30008 0R Jumper 0603
4130 4822 051 30008 0R Jumper 0603
COILS & FILTERS
5102 4822 157 62552 Coil 2,2µH 5%
5103 5322 242 73686 Ceram Resonator 12MHz
5104 4822 242 70938 X’tal Resonator 32,768kHz
5900 4822 242 72195 Quartz 4,332MHz
5901 4822 157 10586 2,2µH 10% 0805
5902 4822 157 10586 2,2µH 10% 0805
DIODES
6100 4822 130 30621 1N4148
6101 4822 130 31878 1N4003G
6102 4822 130 30621 1N4148
6103 4822 130 31878 1N4003G
6105 4822 130 34173 BZX79-B5V6
6106 4822 130 30621 1N4148
6107 4822 130 30621 1N4148
6108 4822 130 30621 1N4148
6109 4822 130 30621 1N4148
6110 4822 130 30621 1N4148
6111 4822 130 30621 1N4148
TRANSISTORS & INTEGRATED CIRCUITS
7101 4822 209 15449 74HC4094D
7102 3139 110 52810 TMP88CU74YF "MC50S52811"
7103 4822 130 60511 BC847B
7104 4822 130 60511 BC847B
7105 4822 130 60511 BC847B
7106 4822 130 60511 BC847B
7107 4822 130 60511 BC847B
7900 9352 679 67118 SAA6579T/V1/M4
7901 9322 145 26668 M24C02-WMN6
Note: Only the parts mentioned in this list are normal
service spare parts.
