MECHANICAL & ACCESSORIES PARTS LIST - MAIN UNIT SCREW LISTS - MAIN UNIT
101 3139 118 15230 Cabinet Front /21/21M/37
101 3139 118 15220 Cabinet Front /22
105 3139 118 14920 Button Set DTC Chrome
106 3139 118 15240 Cover Tray DTC
107 4822 459 11086 Badge Name Philips
124 3139 118 15260 Window Display /21/21M/37
124 3139 118 15040 Window Display /22
125 3139 114 71610 Lightguide Wash
126 3139 114 71620 Housing Lightguide Wash
127 3139 118 15010 Button Set Power Chrome
130 3139 114 71770 Button Set Source
131 3139 118 14990 Cap Source Chrome
133 3139 118 14960 Button Set Control Left
134 3139 118 14970 Button Set Control Right
135 3139 118 14980 Button Set Treble/Bass
136 3139 118 14950 Knob Jog Chrome
137 3139 118 14940 Cover Display
138 3139 114 71780 Button Set WOOX
139 3139 118 15000 Cap WOOX Chrome
141 3139 113 27050 Cut Sheet Display
158 3139 118 15250 Cover Cassette
159 3139 118 15060 Window Cassette
189 * 3139 118 15780 Plate Transport
198 3139 114 68620 Door Cassette Left
200 4822 529 10322 Damper Assembly
201 3139 114 68640 Push Catch Left
203 4822 492 11344 Spring Compression
205 4822 402 11245 Bracket Left
207 3139 111 01390 Spring Torsion Left
209 4822 492 42787 Spring Cassette
246 3139 113 27140 Foot Rubber 4mm
252 3139 114 71560 Bracket Combi
253 3139 114 71510 Panel Left
254 3139 114 71520 Panel Right
255 3139 114 71530 Cover Top
256 3139 114 71490 Panel Rear /21/22/37
256 3139 114 73250 Panel Rear /21M
271 3139 114 71010 Stopper Heatsink
350 3139 118 78550 Loudspeaker Box /21/21M/22
350 3139 118 78540 Loudspeaker Box /37
351 4822 303 50063 FM Aerial /21/21M/22
351 4822 320 11094 FM Antenna Wire /37
356 3139 118 78640 Remote Control /21/21M/37
356 3139 118 78630 Remote Control /22
384 4822 303 50082 AM Frame Antenna
385 2422 070 98151
!
Mains Cord /21/21M/22
385 2422 070 98152
!
Mains Cord /37
386 4822 263 21092
!
Adapter Plug 6A 250V /21
387 3139 115 20780 Instruction For Use /21/21M
387 3139 115 20740 Instruction For Use /22
387 3139 115 20750 Instruction For Use /37
1110 4822 361 11161 Cooling Fan KD1206PTS3
1131 3139 110 34970 Flex Cable 19pin 18cm AD
1133 3139 110 35080 Flex Cable 9pin 18cm AD
1134 3139 110 35240 Flex Cable 8pin 28cm AD
1135 3139 110 35230 Flex Cable 7pin 22cm AD
1136 4822 320 12752 Flex Cable 7pin 18cm AD
1137 3139 110 35250 Flex Cable 4pin 12cm AD
1138 3139 110 34970 Flex Cable 19pin 18cm AD
1141 4822 320 12752 Flex Cable 7pin 18cm AD
1142 3139 110 34610 Flex Cable 11pin 18cm AD
1143 3139 110 34950 Flex Cable 7pin 12cm AD
5001 3103 308 30790
!
Mains Transformer /21/21M
5001 3103 308 30780
!
Mains Transformer /22
5001 3103 308 30770
!
Mains Transformer /37
9965 000 07824 Cloth Grille Assembly
Note: Only the parts mentioned in this list are normal
service spare parts.
* Pos 189 is used for transportatiion only, it must be
removed before playing CD.
186 D3 x 10
187 D3 x 10
188 D3 x 10
212 D3 x 12
213 D3 x 12
214 D3 x 12
215 D3 x 12
226 M3 x 6
227 M3 x 6
228 M3 x 6
229 M3 x 6
230 D3 x 10
231 M3 x 10
276 D3 x 12
277 M3 x 10
278 D3 x 10
279 D3 x 16
280 D3 x 8
281 D3 x 10
282 D3 x 10
283 D3 x 10
284 D3 x 10
285 D3 x 10
286 D3 x 10
287 D3 x 10
288 D3 x 10
292 D3 x 10
293 D3 x 20
295 D2 x 8
296 D3 x 10
297 D3 x 10
298 D3 x 10
299 D3 x 10
300 D3 x 10
301 D3 x 10
302 D3 x 10
303 D3 x 10
304 D3 x 12
SCREW LISTS - Power 2001 Module
D2 x 8 Regulator pcb / Heat shield to Heatsink
D2.5 x 8 Regulator Transistor / IC to Heatsink
D3 x 10 Brackets / IC Clamping Springs to Heatsink
M3 x 8 Rectifier diode to Heatsink
To Previous Page
