Philips MC150 User Manual

MC-320/22-1
18
English
Activating and deactivating
SLEEP
The sleep timer enables the system to switch off
by itself after a set period of time. The clock time
needs to be set first before the sleep timer can
be used.
● Press SLEEP on the remote
control repeatly to select
desired time before system
shuts off.
➜ Display shows
SLEEP and
series of time options for
selection: 60, 45, 30,15, OFF, 60.
Clock/Timer
● To deactivate, press SLEEP on the remote
control once or more until OFF is shown, or
press STANDBY ON on the system or
remote control.
Specifications
AMPLIFIER
Output power .......................................... 2 x 5 W RMS
............................................................ 10 W + 10 W MPO
Signal-to-noise ratio .......................... ≥ 62 dBA (IEC)
Frequency response ......... 60 – 16000 Hz, ± 3 dB
Impedance loudspeakers ......................................... 4 Ω
Impedance headphones ................. 32 Ω – 1000 Ω
CD PLAYER
Frequency range .................................. 20 – 20000 Hz
Signal-to-noise ratio ............................................ 75 dBA
TUNER
FM wave range ................................... 87.5 – 108 MHz
MW wave range ................................ 531 – 1602 kHz
Sensitivity at 75 Ω
– mono, 26 dB signal-to-noise ratio ............ 2.8 µV
– stereo, 46 dB signal-to-noise ratio ........ 61.4 µV
Selectivity ................................................................. ≥ 28 dB
Total harmonic distortion ..................................... ≤ 5%
Frequency response ..... 63 – 12500 Hz (± 3 dB)
Signal-to-noise-ratio ...................................... ≥ 50 dBA
TAPE DECK
Frequency response
Normal tape (type I) ... 120 – 10000 Hz (8 dB)
Signal-to-noise ratio
Normal tape (type I) .................................... 48 dBA
Wow and flutter ......................................... ≤ 0.4% DIN
SPEAKERS
Bass reflex system
Dimensions (w x h x d) . 150 x 222 x 183 (mm)
GENERAL INFORMATION
AC Power ..................................... 220 – 230 V / 50 Hz
Dimensions (w x h x d) 156 x 222 x 215.5 (mm)
Weight (with/without speakers) ..................................
............................................................... approx. 4.9 / 2.3 kg
Standby power consumption .......................... < 3 W
Subject to modification

Philips MC150 Specifications

Sound

output power (RMS)	2 x 5 watts
output power (music power)	2 x 10 watts
output power (PMPO)	200 watts

Loudspeakers

main speaker type	2-Way Bass Reflex Speaker System
woofer size	4 inches
tweeter type	Piezo Tweeter

Audio Playback

cassette deck technology	Mechanical tape deck
disc playback media	CD, CD-R and CD-RW compatible
CD loader type	Top

Tuner / Reception

station presets for FM	20
station presets for MW	10
tuner bands	FM, MW

Connectivity

headphone jack	3.5mm stereo jack
rear connections	FM fixed pigtail antenna, MW loop antenna

Dimensions

center unit dimensions	156 x 222 x 216 mm
main speakers dimensions	140 x 222 x 183 mm
product weight	6.1 kg
