Philips MCD149 - Factory Part List - Resistors; Resistor Part Numbers and Locations

Level Item Component Desc Unit Qty Location AppForm ChangeNo MatProInd
...3 0420 1221-000062030 CH-RES,0 OHM1/16W+/-5%0805 PC 2.000 LD001,LD
002
...3 0430 1221-010062020 CH-RES,1R1/16W+/-5%0603 PC 5.000 RD004,RD006
,RD007,RD008,RD023
...3 0440 1221-022022050 CH-RES, 2.2R1/4W+/-5%1206 PC 4.000 R33,R71,R
262,R265
...3 0450 1221-051062020 CH-RES,5.1R1/16W+/-5%0603 PC 2.000 RD039,RD040 T0707019
...3 0460 1221-100062020 CH-RES,10R1/16W+/-5%0603 PC 1.000 RD115
...3 0470 1221-220062020 CH-RES,22R1/16W+/-5%0603 PC 2.000 R1,R2 T0707042
...3 0480 1221-330062020 CH-RES,33R1/16W+/-5%0603 PC 12.000
RD078,RD080,RD082,RD085,RD100,RD
106,R107,RD109,RD111,RD112,RD113
,
RD114
...3 0490 1221-510051020 CH-RES,51R1/10W+/-1%0603 PC 2.000 RD037,RD04
1
...3 0495 1221-680051020 CH-RES, 68R1/10W+/-1%0603 PC 1.000 RD052
...3 0500 1221-750061020 CH-RES, 75R1/16W+/-1%0603 PC 5.000 R17,R18,R
D3,RD11,RD16
...3 0510 1221-820061020 CH-RES,82R1/16W+/-1%0603 PC 1.000 RD17
...3 0520 1221-101062020 CH-RES,100R1/16W+/-5%0603 PC 9.000
R266,R267,RD73,RD76,RD079,RD083,
RD084
,
RD087
,
RD155
...3 0530 1221-121061020 CH-RES,120R1/16W+/-1%0603 PC 1.000 RD036
...3 0540 1221-331062020 CH-RES,330R1/16W+/-5%0603 PC 9.000
R3,R4,R29,R30,R248,R250,R251,RD0
65
,
RD066
T0707042
...3 0550 1221-361061020 CH-RES,360R1/16W+/-1%0603 PC 1.000 RD118
...3 0560 1221-471062020 CH-RES,470R1/16W+/-5%0603 PC 2.000 RD029,RD0
43
...3 0565 1221-102061020 CH-RES,1K 1/16W +/-1% 0603 PC 4.000 R49,R56,
R57,R61
...3 0570 1221-102062020 CH-RES,1K1/16W+/-5%0603 PC 13.000
R22,R76,R77,RD051,RD056,RD057,RD
058,RD059,RD060,RD092,RD095,RD10
8
,
RD182
T0707042
...3 0580 1221-122061020 CH-RES,1.2K 1/16W +/-1% 0603 PC 1.000 RD093
...3 0590 1221-152062020 CH-RES,1.5K1/16W+/-5%0603 PC 1.000 RD094
...3 0600 1221-202062020 CH-RES,2K1/16W+/-5%0603 PC 6.000 R205,R206,R209,R210,R270,R271
...3 0610 1221-222062020 CH-RES,2.2K1/16W+/-5%0603 PC 1.000 RD054
...3 0620 1221-272062020 CH-RES,2.7K1/16W+/-5%0603 PC 1.000 R13 T07070
42
...3 0630 1221-332062020 CH-RES,3.3K1/16W+/-5%0603 PC 2.000 R64,R65 T0
707042 L
...3 0640 1221-362061020 CH-RES,3.6K1/16W+/-1%0603 PC 1.000 R66
...3 0650 1221-472062020 CH-RES,4.7K1/16W+/-5%0603 PC 10.000
R263,R264,RD001,RD002,RD005,RD04
2
,
RD047
,
RD049
,
RD081
,
RD103
T0707042
...3 0660 1221-512062020 CH-RES,5.1K 1/16W+/-5%0603 PC 2.000 RD097,RD
104 T0707042
...3 0670 1221-562062020 CH-RES,5.6K1/16W+/-5%0603 PC 5.000 R268,R269,RD099,RD101,RD102
...3 0680 1221-822062020 CH-RES,8.2K1/16W+/-5%0603 PC 2.000 R254,R256
...3 0690 1221-103061020 CH-RES, 10K1/16W+/-1%0603 PC 1.000 R45
...3 0700 1221-103062020 CH-RES,10K1/16W+/-5%0603 PC 30.000
R5,R11,R19,R23,R24,R47,R53,R54,R
58,R63,R67,R68,R70,R74,R75,R78,R
79,R80,RD71,RD024,RD026,RD45,RD4
6,RD048,RD50,RD061,RD110,RD153,R
D158
,
RD179
T0707042
...3 0710 1221-153062020 CH-RES,15K1/16W+/-5%0603 PC 6.000 R27,R28,RD091,RD098,RD180,RD181
...3 0720 1221-203062020 CH-RES,20K1/16W+/-5%0603 PC 1.000 RD096 T0707019
...3 0730 1221-223062020 CH-RES,22K1/16W+/-5%0603 PC 3.000 R260,R261,RD031
...3 0740 1221-303061021 CH-RES,30.9K1/16W+/-1%0603 PC 1.000 R46
...3 0745 1221-303062020 CH-RES,30K1/16W+/-5%0603 PC 1.000 R51 T070704
2
...3 0750 1221-333061020 CH-RES, 33K1/16W+/-1%0603 PC 1.000 RD064
...3 0760 1221-333062020 CH-RES,33K1/16W+/-5%0603 PC 6.000 R42,R44,R252,R253,R258,R259
...3 0765 1221-363062020 CH-RES,36K1/16W+/-5% 0603 PC 2.000 R201,R202 T0707042
...3 0770 1221-393062020 CH-RES,39K1/16W+/-5%0603 PC 3.000 R203,R204,RD053 T0707019
...3 0780 1221-473062020 CH-RES,47K1/16W+/-5%0603 PC 10.000
R32,R40,R41,R48,R59,R60,R72,R73,
RD009
,
RD074
...3 0790 1221-513051020 CH-RES,51K1/10W+/-1%0603 PC 1.000 R52
...3 0800 1221-563062020 CH-RES,56K1/16W+/-5%0603 PC 1.000 RD062 T0707019
...3 0810 1221-104062020 CH-RES,100K1/16W+/-5%0603 PC 9.000
R50,R246,R247,R255,R257,RD028,RD
044
,
RD067
,
RD086
T0707042
...3 0820 1221-124062020 CH-RES, 120K1/16W+/-5%0603 PC 1.000 RD063 T07
07019
...3 0830 1221-154062020 CH-RES,150K1/16W+/-5%0603 PC 3.000 RD022,RD027,RD105
...3 0835 1221-474062020 CH-RES,470K1/16W+/-5%0603 PC 2.000 RD025,RD033
...3 0840 1221-105062020 CH-RES,1M1/16W+/-5%0603 PC 2.000 R55,R69
...3 0850
1221-000012090 CH-RES,0R 1/2W +/-5% 1812
PC 2.000 R21,R89
...3 0860 1225-330062020 CH-ARRAY-RES 33 OHMx4 1/16W +/-5% 0603 PC 4
.000 RND01,RND02,RND03,RND04
...3 0870 1311-140070000 DIODE RECT 1N4007 1A/1000V DO41. PC 1.000 DD008 FAP070564
...3 0875 1313-000680000 ZENER DIODE MTZ6.8B 1/2W PC 1.000 Z1
...3 0880 1321-000990030 CH-SW DIODE, BAV99 SOT23 PC 2.000 D1,D5 FA051735
...3 0890 1321-041480020 CH-DIODE RLS4148 LL-34 PC 3.000 DD001,DD002,DD003
FA060300,
FAP060547
...3 0900 1322-000014000 SCHOTTKY BARRIER RECTIFIER, DIODE SX14,DO-214AC PC 1.000 Z24
...3 0910 1322-000034000 SCHOTTKY BARRIER RECTIFIER, DIODE SX34,DO-214AC PC 1.000 Z26 CAP070152
...3 0915 1323-000510050 CH-ZENER DIODE MM1Z5V1ST(4N) SOD-123 PC 6.000 Z17,Z18,Z19,Z20,Z22,Z23 FAP061252
...3 0920 1323-001200010 CH-ZENER DIODE 12V ZMM12 LL-34. PC 1.000 Z21 T0707042
12-2
FACTORY PARTLIST
