3 - 1
CONNECTION AND CONTROLS
DB15 CONNECTOR
TO MAIN UNIT
SPEAKERS 4
AC MAINS ~
1.000
IMPORTANT!
– The type plate is located at the rear of
the system.
– Before connecting the AC power cord
to the wall outlet, ensure that all other
connections have been made.
–Never make or change any
connections with the power switched on.
– High voltage! Do not open.You run the
risk of getting an electric shock.
– The machine does not contain any user-
serviceable parts.
– Modification of the product could result
in hazardous radiation of EMC or other
unsafe operation.
To avoid overheating of the system, a
safety circuit has been built in. Therefore,
your system may switch to Standby
mode automatically under extreme
conditions. If this happens, let the system
cool down before reusing it (not available
for all versions).
Speaker
(right)
Speaker
(left)
FM antenna
AC pow
er cord
Step 1: Placing speakers and
subwoofer
For best possible surround sound, locate your
speakers and subwoofer as follows:
● Place the left and right speakers at equal
distances from the TV set and at an angle of
approximately 45 degrees from the listening
position.
● Place the subwoofer on the floor.
Notes:
–To avoid magnetic interference, do not position
the front speakers too close to your TV set.
–
Step 3: Antenna connection
Connect the supplied FM antenna to the
respective terminal. Adjust the position of the
antenna for optimal reception.
FM Antenna
●
For better FM stereo reception, connect an
outdoor FM antenna to the FM AERIAL (FM
ANTENNA) terminal.
Step 4: Connecting TV
IMPORTANT!
–You only need to make one video
connection from the following options,
depending on the capabilities of your TV
system.
– Connect the DVD system directly to
the TV.
Using Video In jack (CVBS)
1 Use the composite video cable (yellow) to
connect the system's VIDEO jack to the video
input jack (or labelled as A/V In, Video In,
Composite or Baseband) on the TV set.
2
To
hear the sound of this DVD Player through
y
our TV, use the audio cables (white/red-not
supplied) to connect
LINE OUT (L/R)
jacks of
the DVD Player to the corresponding AUDIO
IN jacks on the TV.
Step 2: Connecting speakers
and subwoofer
● Connect the supplied DB15 cable to DVD
player’s
DB15 CONNECTOR TO
SPEAKER
jack and the Subwoofer’s
DB15
CONNECTOR TO MAIN UNIT
jack.
● Connect the speaker wires to the SPEAKER
terminals on the subwoofer, right speaker to "R"
and left speaker to "L", coloured (marked) wire
to "+" and black (unmarked) wire to "-". Fully
insert the stripped portion of the speaker wire
into the terminal as shown.
Notes:
– Ensure that the speaker cables are correctly
connected. Improper connections may damage the
system due to short-circuit.
–For optimal sound performance, use the
supplied speakers.
– Do not connect more than one speaker to any
one pair of +/- speaker terminals.
– Do not connect speakers with an impedance
lower than the speakers supplied. Please refer to
the SPECIFICATIONS section of this manual.
1.000
DB15 CONNECTOR
TO MAIN UNIT
SPEAKERS 4
1.000
