CONNECTION AND CONTROLS
Using an accessory RF modulator
IMPORTANT!
– If your TV set only has a single
Antenna In jack (or labelled as 75 ohm or
RF In), you will need a RF modulator in
order to view the DVD playback via TV.
See your electronics retailer or contact
Philips for details on RF modulator
a
vailability and operations.
1
Use the composite cable (yellow) to connect the
system's VIDEO
jack to the video input jack on
the RF modulator.
2 Use an RF coaxial cable (not supplied) to
connect the RF modulator to your TV's RF jack.
Using component Video In jack (Pr Pb Y)
● Use the component video cables (red/blue/
green, not supplied) to connect the system’s PR/
PB/ Y jacks to the corresponding Component
video input jacks (or labeled as Pr/Cr Pb/Cb Y or
YUV) on the TV set.
● To listen to TV channels through this system, use
the audio cables (white/red) to connect
AUX
IN (L/R) jacks to the corresponding AUDIO
OUT jacks on the TV set.
1.
000
Using Scart jack
1 Use the scart cable (not supplied) to connect
the system’s TV SCART OUT jack to the
corresponding SCART input jacks on the TV set.
1.000
TO TV
TO TV
2 To listen to TV channels through this system, use
the scart cable (not supplied) to connect the
system’s TV SCART OUT jack to the
corresponding SCART output jack on the TV set.
● Before starting operation, press AUX on the
remote control to select “TV” in order to
activate the input source. The music will be heard
through the speakers.
1.000
AUDIO IN
R L
VIDEO
IN
TO TV
ANT IN
CH3 CH4
RF coaxial cable to TV
Back of RF Modulator
(example only)
Antenna or
Cable TV signal
Step 5: Connecting the power
cord
IMPORTANT!
–Nev
er make or change any connection
with the power switched on.
the AC power cord to the system and then to
the power outlet.
Optional: Connecting additional
equipment
IMPORTANT!
– Some discs are copy-protected. You
cannot record the disc through a VCR or
digital recording device.
–When making connections, make sure
the colour of cables matches the colour
of jacks.
–Always refer to the owner's manual of
the other equipment for complete
connection and usage details.
1
.000
A
UDIO OUT
L
R
A
Listening to the playback of other
equipment A
Use a cinch cable (not supplied) to connect
AUX on the rear panel of the DVD player to the
analogue audio out terminals of an external
equipment (TV, VCR, Laser Disc player, DVD
player or CD Recorder).
Before starting operation, press SOURCE on
the front panel to select AUX or press AUX on
the remote in order to activate the input source.
Note:
–
If you are connecting equipment with a mono
output (a single audio out terminal), connect it to
the AUX left terminal. Alternatively, you can use a
“single to double” cinch cable (the output sound
still remain mono).
1.
000
A
UDIO IN
L
R
VIDEO IN
L
B
Using the VCR for recording DVDs
B
Connect one of the system's
VIDEO OUT
jacks to the corresponding VIDEO IN jack and
LINE OUT (R/L) jacks to the AUDIO IN jacks
on the VCR. This will allow you to make analogue
stereo (two channel, right and left) recordings.
Connecting a USB device or memory
card
By connecting a USB mass storage device
(including USB flash memory, USB flash players
or memory cards) to the system, you can enjoy
the device's stored music through the powerful
speakers of the system.
● Insert the USB device's USB plug into the
socket on the set.
for the devices with USB cables:
1 Insert one plug of the USB cable (not supplied)
to the
socket on the set.
2 Insert the other plug of the USB cable to the
USB output terminal of the USB device.
for the memory card:
1
Insert the memory card into a card reader (not
supplied).
2 Use a USB cable (not supplied) to connect the
card reader into the socket on the set.
Step 6: Connecting digital
audio equipment
1.
000
D
igital audio recorder
