Level Item Component Desc Unit Qty Location AppForm ChangeNo MatProInd
0 0010 9007-014900012 PHILIPS MCD149//12 SET 1.000
.1 0010 8900-071000100 ELECTRICAL SECTION OF MCD149/12 SET 1.000
..2 0010 8901-071000100 MAIN PWB ASSEMBLY OF MCD149/12 SET 1.000
...3 0010 1001-270000250 CRYSTAL 27MHz 20PPM 30PF HC-49/S PC 1.000 XTD01
FAP070569
FAP070550
...3 0015 1112-108043291 CAP ELECT, 1000UF10V+/-20%8X14 105DEGREE. PC 1.000 C82 T0707042
...3 0020 1121-100081020 CH-CAP, CER 10PF50V+/-5%0603 PC 4.000 CD002,
CD010,CD024,CD080
...3 0030 1121-300082020 CH-CAP, CER 30PF50V+/-10%0603 PC 1.000 CD029
...3 0040 1121-330081020 CH-CAP, CER33PF50V+/-5%0603 PC 7.000
C241,C242,CD015,CD049,CD055,CD06
1
,
CD063
...3 0060 1121-470081020 CH-CAP, CER47PF50V+/-5%0603 PC 11.000
C34,C35,C36,C37,C38,C39,C40,C41,
C55
,
CD053
,
CD054
...3 0070 1121-510081020 CH-CAP, CER 51PF 50V +/-5% 0603 PC 2.000 CD0
64,CD065
...3 0080 1121-101081020 CH-CAP, CER100PF50V+/-5%0603 PC 10.000
C77,CD001,CD003,CD009,CD011,CD02
3
,
CD025
,
CD062
,
CD087
,
CD091
...3 0090 1121-151081020 CH-CAP, CER150PF50V+/-5%0603 PC 2.000 CD008,CD013
...3 0100 1121-301081020 CH-CAP, CER300PF50V+/-5%0603 PC 1.000 CD031
...3 0110 1121-391082020 CH-CAP, CER390PF50V+/-10%0603 PC 2.000 GD201
,GD202
...3 0120 1121-681081020 CH-CAP, CER 680PF50V+/-5%0603 PC 6.000
C60,CD037,CD038,CD040,CD041,CD04
6
T0707019
...3 0130 1121-821082020 CH-CAP, CER 820PF50V+/-10%0603 PC 1.000 CD02
8
...3 0140 1121-102081020 CH-CAP, CER 1000PF50V+/-5%0603 PC 8.000
C235,C236,CD032,CD033,CD211,CD26
7
,
CD268
,
EMC1
...3 0150 1121-122082020 CH-CAP,CER1200PF 50V+/-10% 0603 PC 2.000 CD0
48,CD060
...3 0160 1121-222082020 CH-CAP, CER 2200PF50V+/-10%0603 PC 2.000 CD0
66,CD067
...3 0170 1121-272082020 CH-CAP, CER 2700PF50V+/-10%0603 PC 2.000 C25
1,C252
...3 0180 1121-332082020 CH-CAP, CER3300PF50V+/-10%0603 PC 2.000 CD01
2,CD058
...3 0190 1121-472082020 CH-CAP, CER4700PF50V+/-10%0603 PC 2.000 CD016,CD018
...3 0200 1121-103082020 CH-CAP, CER0.01UF50V+/-10%0603 PC 6.000
C75,CD034,CD035,CD052,CD057,CD21
3
...3 0210 1121-223082020 CH-CAP, CER 0.022UF 50V +/-10% 0603 PC 2.00
0 C58,C76
...3 0220 1121-473082020 CH-CAP, CER0.047UF50V+/-10%0603 PC 1.000 CD0
30
...3 0230 1121-683082020 CH-CAP,0.068UF50V+/-10%0603 PC 1.000 CD047
...3 0240 1121-104082020 CH-CAP, CER0.1UF50V+/-10%0603 PC 85.000
C8,C27,C32,C43,C48,C51,C53,C57,C
59,C62,C64,C65,C79,C81,C84,C238,
C250,C254,C255,C261,C262,C263,C2
64,CD004,CD020,CD022,CD026,CD027
,CD056,CD070,CD071,CD073,CD075,C
D076,CD078,CD201,CD202,CD203,CD2
04,CD205,CD206,CD207,CD208,CD209
,CD210,CD212,CD214,CD215,CD216,C
D217,CD218,CD219,CD221,CD222,CD2
24,CD225,CD226,CD227,CD229,CD230
,CD231,CD232,CD236,CD237,CD239,C
D240,CD241,CD242,CD246,CD251,CD2
52,CD253,CD259,CD261,CD264,ESD1,
ESD2,ESD3,ESD4,ESD5,ESD6,ESD7,ES
D8,ESD9,GD003
T0707030
...3 0250 1121-224082020 CH-CAP, CER0.22UF50V+/-10%0603 PC 1.000 CD036
...3 0270 1121-105082020 CH-CAP, CER 1UF50V+/-10%0603 PC 5.000 C47,CD039,CD045,CD050,CD051
...3 0280 1121-225044020 CH-CAP, CER2.2UF10V+80%-20%0603 PC 8.000 C1,C2,C3,C4,C5,C6,C45,C46
...3 0290 1121-226044170 CH-CAP, CER 22UF 10V +80%-20% 1210 Y5V PC 1.000 C50
...3 0300 1132-225083060 CAP ELECT, 2.2UF 50V +/-20% 5X11 TAPING PC 2.000 C253,C265
...3 0310 1132-106053060 CAP ELECT, 10UF 16V +/-20% 5X11 TAPING PC 6.000
CD317,CD319,CD322,CD323,CD336,CD
344
...3 0320 1132-106083060 CAP, ELECT 10UF 50V +/-20% 5X11 TAPING PC 3
.000 C61,C237,C240
...3 0325 1132-106083710 CAP ELECT 10UF 50V +/-20% 5X8 85C TAPING P
C 2.000 C243,C244
...3 0330 1132-226083060 CAP ELECT, 22UF 50V +/-20% 5X11 TAPING PC 1.000 C256
...3 0340 1132-476053060 CAP ELECT, 47UF 16V +/-20% 5X11 TAPING PC 4.000 CD308,CD309,CD311,CD312
...3 0350 1132-476083720 CAP ELECT 47UF 50V +/-20% 6.3X8 85C TAPING PC 2.000 C63,C78
...3 0360 1132-107053060 CAP ELECT, 100UF 16V +/-20% 5X11 TAPING PC 35.000
C7,C25,C33,C44,C54,C66,C67,C68,C
69,C70,C71,C72,C83,C87,C88,CD301
,CD302,CD303,CD304,CD305,CD306,C
D307,CD310,CD315,CD316,CD320,CD3
21,CD324,CD335,CD338,CD339,CD341
,CD342,CD343,CD347
...3 0365 1132-107053710 CAP ELECT 100UF 16V +/-20% 85C 5X8 TAPING
PC 4.000 C26,C49,C56,C245 T0707042
...3 0370 1132-107083220 CAP ELECT,100UF 50V +/-20% 8x12 TAPING PC 1
.000 C52
...3 0380 1132-227053060 CAP ELECT, 220UF 16V +/-20% 5X11 TAPING PC
3.000 C239,C249,CD325
...3 0400 1214-033000001 THERMISTOR PTC 0.33OHM 40A 72V JK60-075F PC 1.000 F1 FAP070603
...3 0405 1221-000042050 CH-RES,0R 1/8W +/-5% 1206 PC 1.000 R62 T0707019
...3 0410 1221-000062020 CH-RES,0 OHM1/16W+/-5%0603 PC 36.000
DA1,DM1,R16,R20,R25,R31,R34,R35,
R36,RD010,RD012,RD014,RD015,RD01
9,RD021,RD035,RD055,RD069,RD077,
RD088,RD090,RD116,RD165,RD166,RD
203,RD239,RD261,RDV1,RDV2,RFD1,L
D028,LD032,LD037,LD039,LD040,LD0
41
T0707042
12-1
