Philips MCD149 - Factory Part List - Labels and Miscellaneous; Labels and Miscellaneous Part Details; Accessories and Mechanical Parts

Level Item Component Desc Unit Qty Location AppForm ChangeNo MatProInd
...3 0190 7111-071000100 LABEL TYPE PLATE(MCD149/12) 52X37MM. PC 1.0
00 L
...3 0200 7101-071000100 LABEL CARTON BOX(MCD149/12) 83x103MM. PC 1.
000 L
...3 0210 7103-030300100 LABEL DON'T TOUCH THE LENS PC 1.000
FA040034,
FAP070872
L
...3 0220 7110-030700100 LABEL "DESIGNED BY PHILIPS" PC 1.000
FA040468,
FA051193
L
...3 0230 7107-042500100 LABEL QC (TAI CHUNG LAM) PC 1.000
FA050450,
FA050713
L
...3 0240 7111-071000200 LABEL TYPE PLATE FOR SPEAKER (MCM149/12) 42x30MM PC 1.000 L
...3 0250 7102-030600100 BLANK LABEL WHITE 101x101MM FOR PALLET PC 0
.070 L
...3 0260 7206-030800100 SLIP SHEET 1400X1250MM PC 0.030 FA051273 L
...3 0270 7206-030500200 WRAP FILM M 0.600 L
...3 0280 7206-042500100 FITTING PALLET 46.125"X38.75" (3140 10638732) PC 0.030 FA050791 L
..2 0050 8945-070900100 MINISTRANT PART OF MCD119/12 SET 1.000
...3 0010 7902-060400200 DOUBLE SIDE TAPE 127.8x57.2 PC 1.000 FORLENSDISPLAY FAP061577 L
...3 0020 7902-042000100 NITTO 500 DOUBLE SIDE TAPE 12x120MM PC 1.000 FORLENSDOORCD FA060184 L
...3 0030 7902-042500100 DOUBLE SIDE TAPE 20X12MM PC 2.000 FORLENSDOO
RCD FA060185 L
...3 0040 7908-060400100 UL ADHESIVE PLASTER 17X30MM (BLACK) PC 1.00
0L
.1 0040 8944-071000100 ACCESSORIES OF MCD149/12 SET 1.000
..2 0010 1901-000004600 REMOTE CONTROL "PHILIPS" (MCD119) (12NC:31
39 XXXXXXXX) PC 1.000
..2 0020 2902-125007150
AC CORD VDE H03VVH2-F AND IEC 52(RVV) 2Cx0.75MM2 SF-
103/SF-106 2.5A 250V
PC 1.000 FAP070407
..2 0030 3001-001000100 FM ANT WIRE 75OHM 1.0M PC 1.000 FA050443
..2 0040 3007-001500500 RCA CABLE FOR COMPOSITE VIDEO (YELLOW) 1C
L=1500MM PC 1.000 FA040486
..2 0050 3007-021500000 RCA CABLE FOR AUDIO (RED/WHITE) 2C L=1500M
M PC 1.000 FA040487
..2 0060 3007-031500000
RCA CABLE FOR COMPONENT VIDEO (RED/BLUE/GREEN) 3C
L=1500MM
PC 1.000 FA040485
..2 0070 3010-001500100 CABLE HDB 15P/M TO HDB 15P/M L=1500MM PC 1.000 FAP061552
..2 0075 3506-040250000 CABLE USB A/M TO USB A/F L=250MM PC 1.000 FAP061551 T0707022
..2 0090 8919-071000300 SPEAKER BOX OF MCD149/12. SET 1.000
...3 0010 8919-071000700
SPEAKER BOX AND SUBWOOFER FROM EASTECHFOR MCD149/12
W/POS
SET 1.000 T0707028
...3 0020 8940-071000200 MECHANICAL PART OF SUBWOOFER MCD149/12 SET
1.000
....4 0010 6215-071000100 PLATE BACK PC 1.000
....4 0020 6306-071000100 BRACKET POWER PCB PC 5.000
....4 0030 6306-071000200 BRACKET MAIN PCB PC 2.000
....4 0040 6306-071000300 BRACKET AC JACK PCB PC 1.000
....4 0050 6023-230060100 SCREW, M B B3X6B PC 16.000 8-PLATEBACK+PCB,
8-BRACKETPCB+PCB FA051219 T0707037
....4 0060 6013-230080100 SCREW, ST B B 3X8 B PC 4.000
1-PLATE BACK+AC JACK,2-
PLATEBACK+SPEAKER JACK,1-BRACKET
PCB B+HEATSINK
FA060178 T0707037
....4 0070 6013-130140100 WOOD SCREW,B A 3.0X14MM B PC 10.000 4-PLATE
BACK+SPEAKERBOX FAP061150
....4 0080 6033-226080100 HARDNESS SCREW B B2.6X8 B (A022608002) PC 2.000 2-PLATEBACK+15PJACK FAP061169
....4 0090 6013-226140100 SCREW, ST B B 2.6x14 BLACK A222614002 PC 4
.000 4-FAN-BACKPLATE FAP061148
12-8
FACTORY PARTLIST
