Small Board Diagram
ML
MR
B
ASP 12V
G
R
RGB
CVB1
GND
R1506
100
R1507
100
R1505
10K
R1504
10K
21
1.R-CH OUT
2.R-CH IN
3.L-CH OUT
4.AUDIO GND
5.BLUE GND
6.L-CH IN
7.BLUE
8.12V
9.GREEN GND
10.CLOCK
11.GREEN
12.REMOTE
13.RED GND
14.REMOTE GND
15.RED
16.FS
17.VIDEO GND
18.FS GND
19.VIDEO OUT
20.VIDEO IN
GND
J1501
SCART-101 (HUAHUI)
GND
R
G
B
CVB1
From dvd decoder
1
2
3
4
5
6
7
8
9
10
CN1501
10P
RGB
ML
MR
ASP 12V
GND
35-MCD909-15A1
Scart Board
1
2
3
4
CN201
4P/2.0
1
2
3
4
J201
USB
+5V
GND
DM
DP
+5V
GND
DM
DP
35-MCD909-02A1
USB Board
G
1
B
2
A
3
ENCODER801
ENCODER
1
2
3
CN801
VOL BLOCK
ROTA
ROTB
VGND
35-MCD909-08A1
Encoder Board
12
SW1701
5.0
1
2
CN1701
35-MCD909-17A1
AD1
GND
Push Key Board
