Philips MCD909 - Factory Partlist

14-1
FACTORY PART LIST
MCD909/12 DVD UNIT PARTS ASS'Y
MCD909/12 DISPLAY BOARD
CARBON FILM RESISTOR 3.3 1/2W-52
CARBON FILM RESISTOR 3.3 1/2W-52
CARBON FILM RESISTOR 4.7K 1/8W J-52
CARBON FILM RESISTOR 4.7K 1/8W J-52
CHIP CERAMIC CAP.104p 50V K-5
CHIP CERAMIC CAP.104p 50V K-5
CHIP CERAMIC CAP.104p 50V K-5
CHIP CERAMIC CAP.104p 50V K-5
CARBON FILM RESISTOR 10K 1/8W J-52
CARBON FILM RESISTOR 10K 1/8W J-52
CARBON FILM RESISTOR 33K 1/8W
J-52
CARBON FILM RESISTOR 33K 1/8W J-52
CARBON FILM RESISTOR 33K 1/8W J-52
CARBON FILM RESISTOR 33K 1/8W J-52
CARBON FILM RESISTOR 47K 1/8W J-52
ELECTROLYTIC CAP.47u 16V L-5 5X5
ELECTROLYTIC CAP.47u 16V L-5 5X5
DIODE 4148-52
DIODE 4148-52
DIODE 4148-52
LED 3R4CB71D-2B-208 (BLUE)
IC PT6311/SC16311/CD16311 (H=1.4)
NE-705D-2.GB VFD DISPLAY
A031
R603
R604
R601
R613
C602
C603
C604
C605
R609
R610
R605
R606
R607
R608
R602
C601
C606
D601
D602
D603
LED601
IC601
VFD601
MCD909/12 AMP UNIT PARTS ASS'Y
MCD909 AMP
BOARD
CHIP RESISTOR 10 1/4W J (1206)
CHIP RESISTOR 10 1/4W J (1206)
CARBON FILM RESISTOR 15 1/4W J-52
CHIP RESISTOR 680 1/16W J (0805)
CHIP RESISTOR 680 1/16W J (0805)
CHIP RESISTOR 680 1/16W J (0805)
CHIP RESISTOR 680 1/16W J (0805)
CHIP RESISTOR 10 1/16W J (0805)
CHIP RESISTOR 10 1/16W J (0805)
CHIP RESISTOR 100 1/16W J (0805)
CHIP RESISTOR 100 1/16W J (0805)
CHIP RESISTOR 100 1/16W J (0805)
CHIP RESISTOR
100 1/16W J (0805)
CHIP RESISTOR 1K 1/16W J (0805)
CHIP RESISTOR 1K 1/16W J (0805)
CHIP RESISTOR 1K 1/16W J (0805)
CHIP RESISTOR 1K 1/16W J (0805)
CHIP RESISTOR 10K 1/16W J (0805)
CHIP RESISTOR 10K 1/16W J (0805)
CHIP RESISTOR 10K 1/16W J (0805)
CHIP RESISTOR 10K 1/16W J (0805)
CHIP RESISTOR 10K 1/16W J (0805)
CHIP RESISTOR 10K 1/16W J (0805)
CHIP RESISTOR 10K 1/16W J (0805)
CHIP RESISTOR 10K 1/16W J (0805)
CH
IP RESISTOR 10K 1/16W J (0805)
CHIP RESISTOR 10K 1/16W J (0805)
AMP
B029
R319
R320
R342
R171
R172
R173
R174
R317
R318
R1392
R1340
R1341
R1389
R1379
R1378
R1393
R345
R129
R130
R132
R133
R150
R151
R159
R160
R346
R347
