Philips MCD909 - Page 40

14-6
FACTORY PART LIST
MCD909/12 ECO POWER CONTROL BOARD
RELAY 10A 240VAC-30VDC HLS-14F1L-DC12V-C
RECTIFIER DIODE 4001-52
RECTIFIER DIODE 4001-52
RECTIFIER DIODE 4001-52
RECTIFIER DIODE 4001-52
RECTIFIER DIODE 4001-52
CARBON FILM RESISTOR 33K 1/8W J-52
CARBON FILM RESISTOR 4.7K 1/8W J-52
CARBON FILM RESISTOR 10 1/4W J-52
B025
REL400
D400
D401
D402
D403
D404
R400
R402
R401
MCD909/12 MAIN SPEAKER BOX
MCD908 FREQUENCY DIVIDER BOARD
CEMENT RESISTOR 4.7 10W J
CEMENT RESISTOR
4.7 10W J
NON-POLARITG ELEC.CAP.5.6u 100V M SNP
NON-POLARITG ELEC.CAP.5.6u 100V M SNP
NON-POLARITG ELEC.CAP.1u 100V M SNP
NON-POLARITG ELEC.CAP.6.8u 100V M SNP
SILICON INDUCTOR 0.9mH
SILICON INDUCTOR 0.05mH
HOLLOW INDUCTOR 0.3mH
ACC2
R5
R6
C2
C3
C4
C5
L1
L3
L2
PRC507-01A REMOTE CONTROL BOARD
CHIP RESISTOR 10 1/16W J (0805)
CHIP RESISTOR 1K 1/16W J (0805)
CHIP RESISTOR 1K 1/16W J (0805)
CHIP RESISTOR 1K 1/16W J (0805)
CHIP RESISTOR 1K 1/16W J (0805)
CHIP RESISTOR 5.6 1/16W J (0805)
CHIP RESISTOR 56 1/16W J (0805)
CHIP RESISTOR 300 1/16W J(0805)
CHIP RESISTOR 300 1/16W J(0805)
CHIP RESISTOR 300 1/16W J(0805)
ELECTROLYTIC CAP.100u 10V M 5X7
CHIP CAP.30p 50V J(0805) NP
O
CHIP CAP.30p 50V J(0805) NPO
CHIP DIODE 4148
LED 2.6X7X7.6 1L2745B12E0DI001
LED 2X5X7 1L2545B12E0DE002
LED 2X5X7 1L2545B12E0DE002
INFRARED-EMITTING DIODE ĭ3
CHIP TRANSISTOR BC817-25(SOT23)
CHIP TRANSISTOR 8050(SOT-23)
CHIP TRANSISTOR 8050(SOT-23)
CHIP TRANSISTOR 8050(SOT-23)
IC TM58P20SC(0310)
CERAMIC CRYSTAL OSCILLATOR 4.19mHz
R11
R1
R5
R8
R10
R3
R7
R6
R9
R4
C1
C2
C3
Q5
D3
D2
D4
D1
Q1
Q2
Q3
Q4
U1
XY1
