Philips MX3550D/37S - Electrical Parts List

9-4
ELECTRICAL PARTS LIST - RGB BOARD (FOR /37 & /37S VERSIONS ONLY)
ELECTRICAL PARTS LIST - SCART BOARD (FOR /22S VERSION ONLY)
MISCELLANEOUS
JK101 9965 000 12611 SCART SOCKET
JK103 9965 000 14211 VIDEO OUTPUT YEL
JK401 9965 000 12607 DIN JACK, S-VIDEO OUT
CAPACITORS
C1001 4822 124 40248 10uF20% 63V
C1002 4822 124 40248 10uF20% 63V
C1003 9965 000 12590 15pF 50V 5%
C1004 9965 000 12590 15pF 50V 5%
C1005 9965 000 12590 15pF 50V 5%
C1006 9965 000 12590 15pF 50V 5%
C1007 9965 000 12590 15pF 50V 5%
C1008 9965 000 12590 15pF 50V 5%
C1009 9965 000 12590 15pF 50V 5%
C1010 9965 000 12590 15pF 50V 5%
C1011 9965 000 12590 15pF 50V 5%
RESISTORS
R1001 9965 000 12519 1K OHM 1/6W 5% CF
R1002 9965 000 12519 1K OHM 1/6W 5% CF
R1003 4822 050 21003 10K00 1% 0,6W
COILS & FILTERS
FB137 9965 000 12470 BEAD FERITE 100R/ AT 100MHZ
FB138 9965 000 12470 BEAD FERITE 100R/ AT 100MHZ
FB139 9965 000 12470 BEAD FERITE 100R/ AT 100MHZ
FB140 9965 000 12470 BEAD FERITE 100R/ AT 100MHZ
FB141 9965 000 12470 BEAD FERITE 100R/ AT 100MHZ
FB142 9965 000 12470 BEAD FERITE 100R/ AT 100MHZ
FB144 9965 000 12470 BEAD FERITE 100R/ AT 100MHZ
FB145 9965 000 12470 BEAD FERITE 100R/ AT 100MHZ
FB146 9965 000 12470 BEAD FERITE 100R/ AT 100MHZ
FB147 9965 000 12470 BEAD FERITE 100R/ AT 100MHZ
DIODES
ZD1101 9965 000 12554 ZENER 3.8-4.0V 0.5W
ZD1102 9965 000 12554 ZENER 3.8-4.0V 0.5W
ZD1103 9965 000 12554 ZENER 3.8-4.0V 0.5W
ZD1104 9965 000 12554 ZENER 3.8-4.0V 0.5W
ZD1105 9965 000 12554 ZENER 3.8-4.0V 0.5W
ZD1106 9965 000 12554 ZENER 3.8-4.0V 0.5W
Note: Only the parts mentioned in this list are normal service spare
parts.
MISCELLANEOUS
JK182 9965 000 14211 VIDEO OUTPUT YEL
JK183 9965 000 12607 DIN JACK, S-VIDEO OUT
JK184 9965 000 12609 RCA JACK R/G/B
CAPACITORS
C181 9965 000 12590 15pF 50V 5%
C182 9965 000 12590 15pF 50V 5%
C183 9965 000 12590 15pF 50V 5%
C185 9965 000 12590 15pF 50V 5%
C186 9965 000 12590 15pF 50V 5%
C187 9965 000 12590 15pF 50V 5%
COILS & FILTERS
FB181 9965 000 12470 FE BEAD D3,5 x 6MM
FB182 9965 000 12470 FE BEAD D3,5 x 6MM
FB183 9965 000 12470 FE BEAD D3,5 x 6MM
DIODES
ZD181 4822 130 31554 BZX79-B4V3
ZD182 4822 130 31554 BZX79-B4V3
ZD183 4822 130 31554 BZX79-B4V3
ZD184 4822 130 31554 BZX79-B4V3
ZD185 4822 130 31554 BZX79-B4V3
ZD186 4822 130 31554 BZX79-B4V3
Note: Only the parts mentioned in this list are normal service spare
parts.
