MECHANICAL & ACCESSORIES PARTS LIST - MAIN UINT SCREW LIST - MAIN UINT
Y01 M3 x 6
Y02 D3 x 6
Y03 D3 x 16
Y04 D3 x 8
Y05 D3 x 8
Y06 D3 x 10
2 9965 000 14096 OPEN / CLOSE KNOB
3 9965 000 14097 LED LENS
4 9965 000 14098 POWER KNOB
5 9965 000 12424 PHILIPS LOGO
6 9965 000 15477 FRONT PANEL MX3550D/37S
6 9965 000 14099 FRONT PANEL MX3600D/37
6 9965 000 14291 FRONT PANEL MX3700D/37S
6 9965 000 14216 FRONT PANEL MX3800D/21H/22S
7 9965 000 14217 POWER LENS /21H/22S
7 9965 000 14100 POWER KNOB TRIM /37
7 9965 000 14292 POWER LENS /37S
8 9965 000 14101 DVD DOOR
9 9965 000 14218 DOOR LENS /21H/22S
9 9965 000 14102 DOOR LENS /37/37S
10 9965 000 14219 VFD LENS /21H/22S
10 9965 000 14103 VFD LENS /37/37S
12 9965 000 14104 VOLUME CAB
13 9965 000 14105 VOLUME SHAFT
14 9965 000 14221 VOLUME RING
15 9965 000 14222 FUNCTION LENS /21H/22S
15 9965 000 14107 FUNCTION KNOB TRIM /37
15 9965 000 14293 FUNCTION LENS /37S
16 9965 000 14108 FUNCTION KNOB
17 9965 000 14109 BASS KNOB
24 9965 000 12437 PCB BRACKET
25 9965 000 14110 FOOT, SILVER
26 9965 000 14111 FOOT, BLACK
27 9965 000 12445 SPACER
39 9965 000 14112 BUSHING FIXED AC CORD
40 9965 000 15983
!
MAINS CORD /21H/22S
40 9965 000 12818
!
MAINS CORD /37/37S
48 9965 000 13082 DVD FE SERVO PCB ASSY KIT572SE
48 9965 000 16291 DVD FE SERVO PCB ASSY KIT772SI
50 9965 000 12822 DVD LOADER MODULE KIT572SE
50 9965 000 15489 DVD LOADER MODULE KIT772SI
51 9965 000 12441 HOLDER
52 9965 000 12817 BUSHING /37/37S
55 9965 000 12455 PCB BRACKET
59 9965 000 12443
!
MAINS SOCKET /21H/22S
9965 000 14633 AM LOOP ANTENNA /21H
9965 000 14114 AM LOOP ANTENNA /22S/37/37S
9965 000 14115 FLEX CABLE 16PINS (CN201 TO DVD)
9965 000 14116 FLEX CABLE 26PINS (CN103 TO DVD)
9965 000 14117 FM ANTENNA
9965 000 16310 INSTRUCTION FOR USE MX3800D/21H
9965 000 14223 INSTRUCTION FOR USE MX3800D/22S
9965 000 14118 INSTRUCTION FOR USE MX3600D/37&
MX3700D/37S
9965 000 15478 INSTRUCTION FOR USE MX3550D/37S
9965 000 13060 REMOTE CONTROL
9965 000 13092 RGB CABLE 3P 1,5M except /22S
9965 000 13059 SCART CABLE 1M /22S
9965 000 14215 SATELLITE SPEAKER PACKAGE FOR
MX3800D/21H/22S
9965 000 14095 SATELLITE SPEAKER PACKAGE FOR
MX355D/37S & MX3600D/37
9965 000 14290 SATELLITE SPEAKER PACKAGE FOR
MX3700D/37S
9965 000 13057 RCA CABLE 1P 5M, SUBWOOFER
9965 000 14119 RCA CABLE 1P 1,2M VIDEO OUT
9965 000 14653 S-VIDEO CABLE
LOUDSPEAKER BOX BREAKDOWN
9965 000 14224 FRONT SPEAKER BOX /21H/22S
9965 000 14120 FRONT SPEAKER BOX /37/37S
9965 000 14225 SURROUND SPEAKER BOX /21H/22S
9965 000 14121 SURROUND SPEAKER BOX /37/37S
9965 000 14226 CENTER SPEAKER BOX /21H/22S
9965 000 14122 CENTER SPEAKER BOX /37/37S
9965 000 11846 GRILLE ASSY, FR/REAR SPK /37/37S
9965 000 11848 GRILLE ASSY, CENTER SPK /37/37S
9965 000 14123 MOUNTING BRACKET
Note: Only the parts mentioned in this list are normal service spare
parts.
