Philips N4520 - N4520 Components List

www.reeltoreel.nl Philip van der Matten ver 4.0 | 24 apr 2024 | page 7/11
audio panel 1 |record/playback PCBs 2B| headphone 3A panel 3B
left right
total:
caps
capacity in µF: V
0,47 63 9 2 7
1 63 4 2 1 1
1,5 63 2 2
3,3 63 2 2
4,7 63 21 6 5 5 5
6,8 40 2 2
15 40 8 2 2 2 2
22 25 13 2 2 2 7
47 10 4 2 1 1
100 25 1 1
150 16 2 2
220 25 2 1 1
total caps: 70 17 12 12 10 19
transistors
BC327/25 2 2
BC337/25 2 2
BC546A 2 2
BC547 1 1
BC547C 2 2
BC548 8 4 4
BC548C 10 3 3 4
BC549 2 2
BC549B 6 6
BC550B 2 1 1
BC556A 2 2
BC557 1 1
BC558 4 2 2
BC558B 4 4
BD135 ?
BF245A 7 7
total transistors 55 19 6 6 14 10
var. resistors/pots:
R(1)36 100kΩ R(1)25 22k
R(1)57 470kΩ R(1)45 10k
R(1)27 22kΩ checken
R40 47kΩ
R41 100kΩ
