Philips PD9016P - Overview of the Main Unit

10 EN
Overview of the main unit
a DVD/AV IN
• Switch to DVD/AV IN mode.
b ON/OFF
• Turns on/off DVD player.
c VOL+/VOL-
• Increases or decreases volume.
d
• Headphone jack.
e AV OUT
• Audio/video output jack.
f 9-12V DC IN
• Power supply socket.
a
c
b
d
e
f
g
h i j k l m n
