Philips QM14.3E LA - Revision List; 1. Revision List; Technical Specifications, Diversity, and Connections; 2.1 Technical Specifications

Revision List
EN 2 QM14.3E LA1.
2014-Apr-17
back to
div. table
1. Revision List
Manual xxxx xxx xxxx.0
• First release.
2. Technical Specs, Diversity, and Connections
Index of this chapter:
2.1
Technical Specifications
2.2 Directions for Use
2.3 Connections
2.4 Chassis Overview
Notes:
• Figures can deviate due to the different set executions.
• Specifications are indicative (subject to change).
2.1 Technical Specifications
For on-line product support please use the CTN links in Table
2-1. Here is product information available, as well as getting
started, user manuals, frequently asked questions and
software & drivers.
Table 2-1 Described Model Numbers and Diversity
2.2 Directions for Use
You can download this information from the following websites:
http://www.philips.com/support
http://www.p4c.philips.com
CTN
2 4 7 9 10 11
Connection Overview
Mechanics Descr. Block Diagrams Schematics Styling
Cable Dressing Assembly Removal Power Supply General Power Architecture Wiring Diagram Video Audio Control & Clock I2C Supply lines Power Supply SSB Amplifier control module (Keyboard Control Module) (Wireless LAN USB, Light Sensor, IR/LED Module) (Sensor Module) (AmbiLight) Styling
42PUK7809/12 2.3 4-1
4-2
4.3 7.3 7.3 9.1 - - - - 9.5 - 10.1 - - - - 10.2 11.1
42PUS7809/12 2.3 4-1
4-2
4.3 7.3 7.3 9.1 - - - - 9.5 - 10.1 - - - - 10.2 11.1
42PUS7809/60 2.3 4-1
4-2
4.3 7.3 7.3 9.1 - - - - 9.5 - 10.1 - - - - 10.2 11.1
49PUK7809/12 2.3 4-3
4-4
4.3 7.3 7.3 9.2 - - - - 9.5 - 10.1 - - - - 10.2 11.2
49PUS7809/12 2.3 4-3
4-4
4.3 7.3 7.3 9.2 - - - - 9.5 - 10.1 - - - - 10.2 11.2
49PUS7809/60 2.3 4-3
4-4
4.3 7.3 7.3 9.2 - - - - 9.5 - 10.1 - - - - 10.2 11.2
55PUK7809/12 2.3 4-5
4-6
4.3 7.3 7.3 9.3 - - - - 9.5 - 10.1 - - - - 10.3 11.3
55PUS7809/12 2.3 4-5
4-6
4.3 7.3 7.3 9.3 - - - - 9.5 - 10.1 - - - - 10.3 11.3
55PUS7809/60 2.3 4-5
4-6
4.3 7.3 7.3 9.3 - - - - 9.5 - 10.1 - - - - 10.3 11.3
