ENGLISH
Replacement Shaver Head Assembly
Indication
C ◗ The shaving unit symbol lights up continuously,
the arrows blink and you will hear a beep
when the shaver is turned off to remind you
to replace your shaving unit to obtain optimal
shaving results.
C 1 Pull the top portion of the shaving unit
straight off the shaver.
C 2 Place the retaining ring holder on the
retaining ring (1), turn counterclockwise
(2) and lift it off the shaving head (3).
3 Remove the retaining ring from the
retaining ring holder and repeat the
process for the other retaining rings.
C 4 Remove the shaving heads from the
shaving head holder and discard.
DO NOT DISCARD THE RETAINING RING.
C 5 Place new shaving heads in the holder.
Make sure the projections of the shaving heads fit
exactly into the recesses.
33
1 2
3
